Image preview - the first page of the document
Samyoung [radial thru-hole] HXL Series


>> Download Samyoung [radial thru-hole] HXL Series documenatation <<

Text preview - extract from the document
                                                                                          MINIATURE ALUMINUM ELECTROLYTIC CAPACITORS


      HXL Series                                105 3,000Hrs assured.
    Non-solvent proof.
    Ultra Low Impedance, Long Life
    Height 7mm.
    For LCD/PDP TV PSU, DVD Driver                                                             HXB                         HXL
    RoHS compliant.
                                                                                                       Long Life
    Halogen-free capacitors are also available.

SPECIFICATIONS
                  Item                                                                                          Characteristics
  Rated Voltage Range                                                                                           6.3 ~ 50 V D C
 Operating Temperature Range                                                                                     -40 ~ +105
  Capacitance Tolerance
