Image preview - the first page of the document



>> Download Samyoung [radial thru-hole] PXB Series documenatation <<

Text preview - extract from the document

                                                          MINIATURE ALUMINUM ELECTROLYTIC CAPACITORS


     PXB Series              125 3,000~5,000Hrs assured.                         Solvent-
                                                                                  proof
                                                                                 WV  80VDC
    Low impedance.
    Wide Temperature range.
    Long Life
    For ECU, BLU, Cooling fan                                 PXA                     PXB
    RoHS compliant.
                                                                        Long Life
    Halogen-free capacitors are also available.


SPECIFICATIONS

              Item                                                                Characteristics

      Rated Voltage Range                      10 ~ 80     VDC                      160 ~ 400     VDC                           450   VDC
  Operating Temperature Range                -40 ~ +125                             -40 ~ +125                            -25 ~ +125
     Capacitance Tolerance
