Image preview - the first page of the document



>> Download Samyoung [screw-terminal] DH Series documenatation <<

Text preview - extract from the document

        LARGE SIZED ALUMINUM ELECTROLYTIC CAPACITORS


            DH Series                 40 1,000,000Times.

            Non-solvent proof.
            For Welding machine, Warning Light
            RoHS compliant.
            Halogen-free capacitors are also available.




SPECIFICATIONS
                   ltem                                                       Characteristics

         Rated Voltage Range                                                    315, 475 VDC
    Operating Temperature Range                                                -25 ~ +70
        Capacitance Tolerance                                                 -10 ~ +50%(T)                       (at 20, 120Hz)

                                            I = 0.06CV or 3, whichever is smaller.
            Leakage Current                 Where, I:Max. leakage current()
                                                    C:Nominal capacitance() V:Rated voltage(VDC)                (at 20, 5 minutes)

      Dissipation Factor (Tan )                                                  0.10 Max.                        (at 20, 120Hz)


     Temperature Characteristics
                                                                          C(-10)/C(20)  0.8
     (Capacitance change ratio)                                                                                        (at 120Hz)

                                           The following specifications shall be satisfied when the capacitors are restored to 40
                                           after the rated working voltage applied. And than charge and discharge (charge
                                           0.8sec. discharge 0.2sec) are repeated 1,000,000 times. And than the capacitors are
                                           restored to 20 after the measurements.
                 Load Life
                                           Capacitance change
