Image preview - the first page of the document



>> Download Samyoung [snap-in] TDA Series documenatation <<

Text preview - extract from the document

      LARGE SIZED ALUMINUM ELECTROLYTIC CAPACITORS


        TDA Series                1 0 5  2 , 0 0 0 H r s a s s u r e d .
      Non-solvent proof.
      Downsized of KMH series.
      For SMPS, Inverter                                              KMH                               TDA
      RoHS compliant.                                                                Downsized
      Halogen-free capacitors are also available.


SPECIFICATIONS

                  ltem                                                                             Characteristics

      Rated Voltage Range                                    16  100 VDC                                                        160  500 VDC
   Operating Temperature Range                              -40  +105                                                           -25  +105
      Capacitance Tolerance
