Image preview - the first page of the document
![Stone [smd] RV Series](/pics/5c2336b719cec.gif)
>> Download Stone [smd] RV Series documenatation <<
Text preview - extract from the document
CHIP TYPE ALUMINUM ELECTOLYTIC CAPACITORS RV
Chip Type Large Capacitance Capacitors
Compatible with surface mounting.
Supplied with carrier taping.
Guarantees 2000 hours at 85 .
Marking color Black print ( 8 6.5L)
SPECIFICATIONS White print on a brown sleeve ( 8 10L 10 10L)
Item Performance
Category temperature range ( ) 40~+85
Tolerance at rated capacitance (%) 20 (20 , 120Hz)
Leakage current ( A) Less than 0.01CV or 3 whichever is larger (after 2 minutes) C Rated capacitance ( F) V Rated voltage (V) (20 )
Rated voltage (V) 6.3 10 16 25 35 50 63 100
Tangent of loss angle (tan ) tan (max.) 0.28 0.24 0.20 0.14 0.12 0.10 0.10 0.10
(20 , 120Hz)
Rated voltage (V) 6.3 10 16 25 35 50 63 100
Characteristics at high Z 25 /Z+20 4 3 2 2 2 2 2 2
Impedance ratio (max.)
and low temperature Z 40 /Z+20 8 5 4 3 3 3 3 3
(120Hz)
Test time 2000 hours
Endurance (85 ) Leakage current The initial specified value or less
(Applied ripple current) Percentage of capacitance change Within 20% of initial value
Tangent of the loss angle 200% or less of the initial specified value
Shelf life (85 ) Test time 1000 hours; other items are the same as those for the endurance. Voltage application treatment According to JIS C5101-1
Frequency (Hz)
50 60 120 1k 10k 100k
Rated voltage (V)
Coefficient of Frequency 6.3 to 16 0.80 1 1.15 1.25
for Rated Ripple Current 25 to 35 0.80 1 1.25 1.40
50 to 63 0.80 1 1.35 1.50
100 0.70 1 1.35 1.50
Applicable standards JIS C5101-1, -18 1998 (IEC 60384-1 1992, -18 1993)
OUTLINE DRAWING Unit mm
Casing
D L A B C W P
symbol
8 6.5 0.3 8.4 8.4 3.4 0.5 to 0.8 2.3 G68
8 10 0.5 8.4 8.4 3.0 0.7 to 1.1 3.1 G10
10 10 0.5 10.4 10.4 3.3 0.7 to 1.1 4.7 H10
STANDARD RATINGS
Rated voltage (V) 6.3 10 16 25 35 50 63 100
Rated Rated Rated Rated Rated Rated Rated Rated
Item Case ESR ripple Case ESR ripple Case ESR ripple Case ESR ripple Case ESR ripple Case ESR ripple Case ESR ripple Case ESR ripple
current current current current current current current current
Rated
D L D L D L D L D L D L D L D L
capacitance (mm) mArms (mm) mArms (mm) mArms (mm) mArms (mm) mArms (mm) mArms (mm) mArms (mm) mArms
( F)
10 8 10 16.6 94
22 8 6.5 7.5 155 8 10 7.5 139 10 10 7.5 189
33 8 6.5 6.0 155 8 6.5 5.0 155 8 10 5.0 139 10 10 5.0 189
47 8 6.5 4.9 155 8 6.5 4.2 155 8 10 3.5 252 10 10 3.5 226
68 10 10 2.4 226
100 8 6.5 4.0 155 8 6.5 3.3 155 8 6.5 2.3 155 8 10 2.0 252 10 10 1.7 458 10 10 1.7 226
220 8 6.5 2.1 155 8 6.5 1.8 155 8 10 1.5 252 8 10 1.1 252 10 10 0.91 458
330 8 6.5 1.4 155 8 10 1.2 252 8 10 1.0 252 10 10 0.70 458
8 10 0.71 252
470 8 10 0.99 252 10 10 0.85 458 10 10 0.49 458
10 10 0.71 458
1000 10 10 0.46 458 10 10 0.34 458
(Note) Rated ripple current 85 , 120Hz ESR 20 , 120Hz
NOTE
Design, Specifications are subject to change without notice. 8
Ask factory for technical specifications before purchase and/or use.
