Image preview - the first page of the document
Sunion [radial thru-hole] CD261 Series


>> Download Sunion [radial thru-hole] CD261 Series documenatation <<

Text preview - extract from the document
CD261
18000~20000h at 105 or 5000h at 125
 High ripple Current High Temperature extremely long life
 Specially desigend for electronic ballast and energy-save lamp,LED
Main technical performance
                  Item                                                              Characteristics
   Operating Temperature Range ()                                                    -40~+125
            Voltage Range (V)                                                          200~450
         Capacitance Range (F)                                                          2.2~33
  Capacitance Tolerance(20,120HZ)
