Image preview - the first page of the document



>> Download Sunion [radial thru-hole] CD266 Series documenatation <<

Text preview - extract from the document

CD266
10000~12000h at 105 or 3000h 125
High ripple Current High Temperature extremely long life
Specially desigend for electronic ballast and energy-save lamp,LED
Main technical performance
                 Item                                                                  Characteristics
  Operating Temperature Range ()                                                         -40~+125
           Voltage Range (V)                                                               200~450
        Capacitance Range (F)                                                               1~100
  Capacitance Tolerance(20,120HZ)
