Image preview - the first page of the document



>> Download Sunion [radial thru-hole] CD268H Series documenatation <<

Text preview - extract from the document

  CD 268H
3000h at 105
 High ripple Current High Temperature
 Specially designed for electronic ballast and energy-save lamp
Main technical performance
                   Item                                                              Characteristics
   Operating Temperature Range ()                                                     -40~+105
            Voltage Range (V)                                                           200~450
         Capacitance Range (F)                                                           2.2~33
  Capacitance Tolerance (20,120HZ)
