Image preview - the first page of the document
Sunion [radial thru-hole] CD50H Series


>> Download Sunion [radial thru-hole] CD50H Series documenatation <<

Text preview - extract from the document
 CD50H
1000h at 105
 5mm height at case dia.4~6.3
Main technical performance
                 Item                                                       Characteristics
   Operating Temperature Range ()                                               -55~+105
           Voltage Range (V)                                                     6.3~50
  Capacitance Range (F)(20,120HZ)                                                0.1~100
      Capacitance Tolerance (%)
