Image preview - the first page of the document
Sunion [radial thru-hole] CD70H Series


>> Download Sunion [radial thru-hole] CD70H Series documenatation <<

Text preview - extract from the document
CD70H
1000h at 105
 7mm Products
 VTR,digital cameras,car radios,micro cassette tape recorder etc
Main technical performance
                   Item                                                             Characteristics
   Operating Temperature Range ()                                                       -55~+105
            Voltage Range (V)                                                             6.3~50
         Capacitance Range (F)                                                           0.1~100
 Capacitance Tolerance (%))(20,120HZ)
