Image preview - the first page of the document
Threecon [snap-in] CD299 Series


>> Download Threecon [snap-in] CD299 Series documenatation <<

Text preview - extract from the document
CD 299
7000h at 105
 Extended Lifetime at 105
 High Ripple Current
 High Professional lndustrial Powew Supplies
Main technical performance
                  ltem                                                            Characteristics
   Operating Temperature Range ()                               -40~+105                                          -25~+105
           Voltage Range (V)                                    160~250                                            315~450
        Capacitance Range (F)                                                        39~2200
  Capacitance Tolerance (20,120HZ)
