Image preview - the first page of the document
Threecon [snap-in] CD291 Series


>> Download Threecon [snap-in] CD291 Series documenatation <<

Text preview - extract from the document
  CD 291
2000h at 85
High Ripple Current
 Smaller size
Main technical performance
                  ltem                                                           Characteristics
  Operating Temperature Range ()                               -40~+85                                            -25~+85
            Voltage Range(V)                                   10~400                                             450~500
         Capacitance Range(F)                                                      100~82000
  Capacitance Tolerance(120HZ,20)
