Image preview - the first page of the document



>> Download Threecon [snap-in] CD292 Series documenatation <<

Text preview - extract from the document

  CD 292
2000h at 85
 High Ripple Current
 Smaller size
Main technical performance
                  ltem                                                           Characteristics
   Operating Temperature Range()                               -40~+85                                             -25~+85
            Voltage Range (V)                                  10~400                                              450~500
        Capacitance Range (F)                                                    120~82000
  Capacitance Tolerance(20,120HZ)
