Image preview - the first page of the document
WT Series Table


>> Download WT Series Table documenatation <<

Text preview - extract from the document
                                   FEATURES              OPERATION     RATED VOLTAGE        CAPACITANCE        SHAPE
PICTURE         SERIES                                                                                                  PDF
                                 APPLICATIONS        TEMPERATURE RANGE      (V)              RANGE (F)        OR TYPE


            CD11(GS)SERIES     Miniature standard          -40~+85            -40~+85         0.1~10000        Radial




           CD110(PT) SERIES    Color tv standard       -40~+85/-25~+85    6.3~100/100~205 0.1~10000/1.0~205    Radial




           CD71(NP) SERIES    Non-polar standard           -40~+85            6.3~100         0.47~6800        Radial




           CD72(BP) SERIES     Non-polar speaker           -40~+85            10~100           0.47~47         Radial




           CD11L(ML) SERIES   Low leakage current          -40~+85            6.3~100         0.1~4700         Radial




           CD11T(MT) SERIES         Long life              -40~+85            6.3~100         1.0~4700         Radial



           CD110X(SX)(7mm)    Super miniature 7mm
                                                          -40~+105            6.3~63           0.1~470         Radial
               SERIES                height



          CD11W(LM) (5mm)     Super miniature 5mm
                                                          -40~+105             4~50           4~50             Radial
              SERIES                 height



                                 For horizontal
            CDS(HX) SERIES                                 -40~+85            10~100           0.47~47         Radial
                                   deflection



              CD13N(PK)        High ripple current         -40~+85           160~450          220~15000        Screw



                               High frequency low
          CD11H(GF)SERIES                                 -40~+105            6.3~250         0.47~6800        Radial
                                   impedance



           CD81(TR) SERIES         High temp          -40~+105/-25~+105   10~100/160~450   1.0~4700/1.0~200    Radial




           AK20(AB) SERIES       Axial bi-polar            -40~+85            50~100           1.0~100         Axial
                      High precision
CD117(SH) SERIES                              -40~+85          10~50    0.47~470    Radial
                         stability



AK10(AN) SERIES        Axial bi-polar         -40~+85         50~100     1.0~200     Axial




   CD13N(PK)        High ripple current       -40~+85         160~450   220~15000   Screw



                        Standard
CD293(BZ)SERIES                               -40~+85         160~400    33~470     Snap-in
                       miniaturized



                     Middle and high
CD11Z(SZ)SERIES                               -40~+85         160~450     1~220      Axial
                     voltage standard



                   Flash lamp circuits in
   CD21S(PS)                                  -20~+55          330V      20~370     Radial
                          camera



   CD294(SK)        high ripple current      -40~+105         10-400v    39-2200    Snap-in



                                   Factory production lines
