Image preview - the first page of the document



>> Download TF Hua-Yu [quick-connect] CDIN Series documenatation <<

Text preview - extract from the document

CDIN SERIES                                               Nantong HuaYu electronic Co., LTD

AALUMINUM ELECTROLYTIC CAPACITORSS

 Load life of 2000 hours at 85
    Fast-on terminal
    High ripple current
    Used for air conditioner
    SPECIFICATIONS
              Item                                                           Characteristics
Operating Temperature Range()                                                      -40~+85
Rated Voltage Range (V)                                                            250~450
Nominal Capacitance Range (F)                                                   220~2500
Capacitance Tolerance(20,120Hz)
