>> Download TF Hua-Yu [screw-terminal] CD13N Series documenatation <<Text preview - extract from the documentCD13N
CD13N Series Aluminum Electrolytic Capacitor
+851000 Load life of 1000 hours at +85
Medium and high voltage, large capacitance, screw, high ripple current.
UPS
Used in storing energy of electric welder and UPS, air conditioners etc.
Specifications
Item Characteristics
Operating temperature range() 40+85 25+85
Rated voltage range(V) 160250 350450
Nominal capacitance range(F) 22018000
Capacitance tolerance(%)
