Image preview - the first page of the document



>> Download TF Hua-Yu [screw-terminal] CD98SK Series documenatation <<

Text preview - extract from the document

CD98SK SERIES
AALUMINUM ELECTROLYTIC CAPACITORSS

 Load life of 3000 hours at 85
 Large capacitance, High ripple current
 used for car audio system
 SPECIFICATIONS
             Item                                                                   Characteristics
Operating Temperature Range()                                                           -40~+85
Rated Voltage Range (V)                                                               16, 20, 25
Nominal Capacitance Range (F)                                                      500000~2000000
Capacitance Tolerance(20,120Hz)
