Image preview - the first page of the document



>> Download Topmay [bi-polar radial] TMCE07-HB Series documenatation <<

Text preview - extract from the document

                                           TMCE07 Bi-Polar Aluminum Electrolytic Capacitor 105


Features
  Load life of 2,000 hours at 105   .
  Bi-polar,low dissipation factor and stable temperature characteristics.
  Allowing high frequency and high ripple current.
  Having safety vents.


Specifications
 Item                                                                                  Characteristics
 Operating temperature range                                                            -40 +105
 Rated voltage range                                                                          50V
 Capacitance range                                                                       2.2-10 F
 Capacitance tolerance
                                                                                             20%(M)
 (at20 ,120Hz)

 Leakage current(I)                      After 1 minute application of rated voltage.
 (at20 )                                 I 100   A


Dissipation factor(Tan    )
(at 20 ,120Hz)                                                                            0.05max



                                                     Impedance ratio                            Z-25    /Z+20                                2
 Low temperature characteristics
 (at 120Hz)                                       ZT/Z+20 (max.)
                                                                                                Z-40    /Z+20                                3

                                         The following specifications shall be satisfied when the capacitors are restored
                                         to 20 after the rated voltage has been applied for 2,000 hours at 105 .with the
                                         polarity inverted every 250 hours.
 Load life
                                                 Capacitance change                                      15% of the initial value
                                                        tan                                            200% of the initial specified value
                                                               I                                       The initial specified value
                                          The following specifications shall be satisfied when the capacitors are restored
                                          to 20 after exposing them at 105 for 500 hours without voltage applied

 Shelf life                                      Capacitance change                                         15% of the initial value
                                                             tan                                       150% of the initial specified value
                                                               I                                       200% of the initial specified value
 Others                                  Satisfies characteristic W of JIS C5102




Dimensions


                                                                             D   0.5         13                   16                    18
                                                                             L   2.0         25        25         30         35         35
                                                                             F 0.5        5.0                          7.5
                                                                             d   0.05     0.6                          0.8




Case Size DxL(mm) and Maximun Ripple curr ent(at DC 12V,15.75kHz)
               Cap.(     F)                            2.2             3.3                4.7                  5.6                6.8               10
                  DxL                                13   25       16    25             16    30             16   30          16    35            18   35
                                    70               5.0AP-P       6.0AP-P              7.0AP-P              7.5AP-P          8.0AP-P            10.0AP-P
  Maximum ripple current            85               3.8AP-P       4.6AP-P              5.4AP-P              5.8AP-P          6.2AP-P            7.7AP-P
                                    105              2.3AP-P       2.7AP-P              3.2AP-P              3.4AP-P          3.6AP-P            4.5AP-P
