Image preview - the first page of the document
![Topmay [lug-terminal] TMCE20-MS Series](/pics/5c2e12314b5e3.gif)
>> Download Topmay [lug-terminal] TMCE20-MS Series documenatation <<
Text preview - extract from the document
TMCE20 MS SERIES ALUMINUM ELECTROLYTIC CAPACITORS
Features
Long life of 75,000 times at 70 (30,000 times for W.V. 160V.AC or more).
Bi-polar, lug terminal type.
For motor staring (compressor starter of a refrigerator, air-comditioner and water pump).
Having safety vents. .
Specifications
Item Characteristics
Operating temperature range -25 +70
Rated voltage range 110 300V.AC
Capacitance range 40 400 F
Capacitance tolerance
0 +20%
(at20 ,120Hz)
Power dissipation factor
(at 20 ,50/60Hz) 0.08(Max.)
The capacitor should withstand 1.2 times of the rated voltage, applied for 2 minutes
Over voltage test
or 1.4 times of the rated voltage, applied for 30 second.
Apply rated voltage to a capacitor at 70 in accordance with the table at underside.
Rated voltage Voltage application cycle Number of applications
110 145V.AC 2 times/min. 1sec. on and 29 sec. off 75,000 times
Load life 160 300V.AC 1 times/min. 1sec. on and 59 sec. off 30,000 times
Capacitors meet the requirement shown down when it was restored at 20 after
completion of the test
Capacitance change 25% of the initial value
Power dissipation factor 0.2
Insulation resistance Between all terminals and mounting fixture:100M or more.
Withstand voltage Between all terminals and mounting fixture:1500V.AC for 1min.
Others Satisfies characteristic W of JIS C4905
Case Size DxL(mm)
W.V.(v)
110 125 145 160 200 220 250 300
Cap.( F)
40 25 40 25 50 25 50 25 60 35 60 35 70 35 80 35 80
50 25 50 25 50 25 60 35 60 35 70 35 80 35 100 35 100
60 25 50 25 60 35 60 30 70 35 80 35 80 35 100 42 100
80 25 60 35 60 30 70 35 60 35 100 35 100 42 100 42 120
100 25 60 30 70 35 60 35 70 35 100 42 100 42 120 50 100
150 30 70 35 70 35 80 35 100 42 100 42 120 50 100 50 120
200 35 60 35 80 35 100 42 100 42 120 50 100 50 120 50 120
250 35 70 35 100 42 100 42 120 50 100 50 120
300 35 80 42 100 42 120 50 100 50 120
400 35 100 42 120
1
TMCE20 MS SERIES ALUMINUM ELECTROLYTIC CAPACITORS
Dimensions
D 25 30 35 42 50
L 40 50 60 60 70 60 70 80 100 100 120 100 120
F 10 10 12 14 20
Terminal type(H,G,N,P)
2
