Image preview - the first page of the document
![Topmay [snap-in] TMCE17-SN Series](/pics/5c2e1243f3d38.gif)
>> Download Topmay [snap-in] TMCE17-SN Series documenatation <<
Text preview - extract from the document
TMCE17 SN Series Aluminum Electrolytic Capacitors
Features
Load life of 2,000 hours at 85 .
Snap-in terminal type.
Applications:audio,video and other filtering applications.
Having safety vents.
Specifications
Item Characteristics
Operating temperature range -40 +85 (for 10V to 250V) -25 +85 (for 315V to 450V)
Rated voltage range 10 450V
Capacitance range 47-82,000 F
Capacitance tolerance
20%(M)
(at20 ,120Hz)
After 1 minute application of rated voltage.
Leakage current(I)
I 0.02CV or 5mA,whichever is smaller.
(at20 )
Where C: Nominal capacitance in F,V:Rated voltage in V.
W.V.(V) 10 16 25 35 50 63 80 100 160 350 400 450
Dissipation factor(Tan ) Tan (max.) 0.50 0.45 0.40 0.35 0.30 0.25 0.20 0.15 0.20
(at 20 ,120Hz)
For capacitance of more than 10,000 F,add 0.02 for every increase of 1,000 F.
W.V.(v) 6.3 10 16 25 100 160 450
Low temperature characteristics
impedance ratio Z-25 /Z+20 4 3 2 6
(at 120Hz)
ZT/Z+20 (max) Z-40 /Z+20 6 4 -
8
The following specifications shall be satisfied when the capacitors are restored to
20 after the rated voltage has been applied for 2,000 hours at 85
Load life Capacitance change 20% of the initial value
tan 200% of the initial specified value
I The initial specified value
The following specifications shall be satisfied when the capacitors are restored
to 20 after exposing them at 85 for 1,000 hours without voltage applied
Shelf life Capacitance change 20% of the initial value
tan 150% of the initial specified value
I 200% of the initial specified value
Others Satisfies characteristic W of JIS C5141
Dimensions
1
TMCE17 SN Series Aluminum Electrolytic Capacitors
Case Size DxL(mm) and Maximun Ripple curr ent(mA/at 85 ,120Hz)
W.V.(V)
10 35
Cap.( F) D 22 25 30 35 22 25 30 35
8,200 22 25 2.08
10,000 22 28 2.18 22 30 2.48 25 25 2.48
12,000 22 30 2.58 22 35 2.90 25 30 2.93
15,000 22 30 2.88 25 25 2.88 22 40 3.44 25 30 3.27 30 25 3.40
18,000 22 35 3.37 25 30 3.40 22 45 3.97 25 35 3.83 30 30 4.00
22,000 22 40 3.95 25 35 4.01 30 25 3.90 22 50 4.60 25 40 4.48 30 30 4.42 35 25 4.53
27,000 22 45 4.61 25 40 4.71 30 30 4.64 25 45 5.22 30 35 5.21 35 30 5.37
33,000 25 45 5.48 30 35 5.47 35 25 5.26 30 40 6.09 35 30 5.94
39,000 25 50 6.24 30 35 5.94 35 25 6.13 30 45 6.96 35 35 6.86
47,000 30 40 6.89 35 30 6.73 30 50 8.00 35 40 7.95
56,000 30 45 7.91 35 35 7.80 35 45 9.12
68,000 35 40 9.07
82,000 35 45 10.46
W.V.(V)
25 35
Cap.( F) D 22 25 30 35 22 25 30 35
3,300 22 25 1.50
3,900 22 30 1.76
4,700 22 30 1.93 25 25 1.93
5,600 22 25 1.83 22 35 2.25 25 30 2.27
6,800 22 30 2.17 25 25 2.17 22 40 2.63 25 30 2.50 30 25 2.59
8,200 22 35 2.55 25 30 2.57 22 45 3.04 25 35 2.93 30 30 3.06
10,000 22 40 2.98 25 30 2.84 30 25 2.94 22 50 3.52 25 40 3.42 30 30 3.38 35 25 3.46
12,000 22 45 3.44 25 35 3.31 30 30 3.46 25 45 3.95 30 35 3.94 35 30 4.06
15,000 22 50 4.03 25 40 3.92 30 30 3.87 35 25 3.96 25 50 4.62 30 40 4.66 35 30 4.54
18,000 25 45 4.52 30 35 4.51 35 30 4.65 30 45 5.36 35 35 5.29
22,000 30 40 5.27 35 30 5.15 35 40 6.17
27,000 30 45 6.14 35 35 6.06 35 45 7.18
33,000 35 40 7.07
39,000 35 45 8.07
W.V.(V) 50 63
Cap.( F) D 22 25 30 35 22 25 30 35
1,500 22 25 1.20
1,800 22 30 1.41
2,200 22 30 1.67 25 25 1.41
2,700 22 25 1.32 22 35 1.96 25 30 1.68
3,300 22 30 1.58 25 25 1.58 22 40 2.28 25 30 1.86 30 25 1.93
3,900 22 35 1.87 25 30 1.88 22 50 2.60 25 35 2.20 30 30 2.30
4,700 22 40 2.15 25 30 2.04 30 25 2.32 25 40 2.53 30 30 2.50 35 25 2.81
5,600 22 45 2.49 25 35 2.39 30 30 2.73 25 45 2.92 30 35 2.92 35 30 3.28
6,800 22 50 2.84 25 40 2.77 30 35 3.20 35 25 3.08 25 50 3.34 30 40 3.37 35 35 3.84
8,200 25 45 3.21 30 40 3.72 35 30 3.63 30 45 3.90 35 40 4.46
10,000 25 50 3.69 30 45 4.32 35 35 4.26 30 50 4.48 35 45 5.17
12,000 30 50 4.95 35 40 4.92 35 50 5.92
15,000 35 45 5.78
18,000 35 50 6.62
2
TMCE17 SN Series Aluminum Electrolytic Capacitors
W.V.(V)
80 100
Cap.( F) D 22 25 30 35 22 25 30 35
680 22 25 0.90
820 22 30 1.07
1,000 22 25 1.09 22 30 1.18 25 25 1.18
1,200 22 30 1.29 22 35 1.38 25 30 1.39
1,500 22 35 1.54 25 25 1.44 22 40 1.63 25 35 1.66 30 25 1.61
1,800 22 40 1.79 25 30 1.70 22 50 1.97 25 40 1.92 30 30 1.90
2,200 22 50 2.42 25 35 2.01 30 25 1.95 25 45 2.24 30 35 2.23 35 25 2.15
2,700 25 40 2.35 30 30 2.32 35 25 2.38 25 50 2.60 30 40 2.61 35 30 2.55
3,300 25 45 2.74 30 35 2.73 35 30 2.82 30 45 3.04 35 35 2.99
3,900 25 50 3.12 30 40 3.14 35 30 3.06 30 50 3.46 35 40 3.44
4,700 30 45 3.62 35 35 3.57 35 45 3.96
5,600 30 50 4.14 35 40 4.12 35 50 4.52
6,800 35 45 4.76
8,200 35 50 5.47
W.V.(V)
160 180
Cap.( F) D 22 25 30 35 22 25 30 35
180 22 25 0.53
220 22 25 0.59 22 30 0.64
270 22 30 0.71 25 25 0.71 22 30 0.71 25 25 0.71
330 22 30 0.83 25 30 0.84 22 35 0.83 25 30 0.84
390 22 35 0.91 25 30 0.91 22 40 0.96 25 35 0.98 30 25 0.95
470 22 40 1.06 25 35 1.07 30 25 1.04 22 45 1.11 25 45 1.07 30 30 1.12
560 22 50 1.27 25 40 1.24 30 30 1.22 25 40 1.24 30 30 1.22 35 25 1.25
680 25 45 1.44 30 35 1.43 35 25 1.38 25 50 1.50 30 35 1.43 35 30 1.48
820 25 50 1.65 30 35 1.57 35 30 1.62 30 40 1.66 35 30 1.62
1 000 30 40 1.84 35 35 1.90 30 45 1.93 35 35 1.90
1 200 30 50 2.21 35 35 2.09 35 40 2.20
1 500 35 45 2.58 35 50 2.70
1 800 35 50 2.96
W.V.(V) 200 250
Cap.( F) D 22 25 30 35 22 25 30 35
120 22 25 0.44
150 22 30 0.53
180 22 25 0.53 22 30 0.58 25 25 0.58
220 22 30 0.64 25 25 0.64 22 35 0.68 25 30 0.69
270 22 35 0.75 25 30 0.76 22 40 0.80 25 30 0.76 30 25 0.79
330 22 40 0.88 25 30 0.84 22 45 0.93 25 35 0.90 30 30 0.94
390 22 45 1.01 25 35 0.98 30 25 0.95 22 50 1.07 25 40 1.03 30 30 1.02 35 25 1.04
470 22 50 1.17 25 40 1.13 30 30 1.12 25 45 1.19 30 35 1.19 35 30 1.23
560 25 45 1.30 30 35 1.30 35 25 1.25 30 40 1.37 35 30 1.34
680 25 50 1.50 30 40 1.51 35 30 1.48 30 45 1.59 35 35 1.57
820 30 45 1.75 35 35 1.72 30 50 1.83 35 40 1.82
1 000 30 50 2.02 35 40 2.01 35 45 2.11
1 200 35 45 2.31 35 50 2.41
1 500 35 50 2.70
3
TMCE17 SN Series Aluminum Electrolytic Capacitors
W.V.(V)
315 350
Cap.( F) D 22 25 30 35 22 25 30 35
82 22 25 0.36
100 22 25 0.40 22 30 0.43
120 22 30 0.47 25 25 0.47 22 30 0.47 25 25 0.47
150 22 35 0.56 25 30 0.57 22 35 0.56 25 30 0.57
180 22 40 0.65 25 30 0.62 30 25 0.64 22 40 0.65 25 35 0.66 30 25 0.64
220 22 45 0.76 25 35 0.73 30 30 0.77 22 50 0.80 25 40 0.78 30 30 0.77
270 22 50 0.88 25 40 0.86 30 30 0.86 35 25 0.90 25 45 0.90 30 35 0.90 35 25 0.87
330 25 45 1.00 30 35 1.00 35 30 1.00 25 50 1.05 30 40 1.05 35 30 1.03
390 30 40 1.15 35 30 1.10 30 40 1.15 35 35 1.19
470 30 45 1.32 35 35 1.30 30 50 1.39 35 35 1.30
560 30 50 1.51 35 40 1.50 35 40 1.50
680 35 45 1.70 35 50 1.82
820 35 50 2.00
W.V.(V)
400 450
Cap.( F) D 22 25 30 35 22 25 30 35
47 22 25 0.24
56 22 25 0.26 22 30 0.28
68 22 30 0.31 22 30 0.31 25 25 0.31
82 22 30 0.34 25 25 0.34 22 35 0.36 25 30 0.36
100 22 35 0.40 25 30 0.40 22 40 0.42 25 30 0.40 30 25 0.42
120 22 40 0.46 25 30 0.44 30 25 0.46 22 50 0.49 25 35 0.47 30 30 0.49
150 22 45 0.54 25 35 0.52 30 30 0.55 25 40 0.55 30 30 0.55 35 25 0.56
180 25 40 0.61 30 30 0.60 35 25 0.61 25 45 0.64 30 35 0.64 35 30 0.66
220 25 50 0.74 30 35 0.71 35 30 0.73 30 40 0.75 35 30 0.73
270 30 40 0.83 35 30 0.81 30 45 0.87 35 35 0.86
330 30 45 0.96 35 35 0.95 30 50 1.01 35 40 1.00
390 30 45 0.96 35 35 0.95 35 45 1.14
470 35 45 1.25 35 50 1.31
Ripple Current Multipliers
Frequency multiplying factor
Freq(Hz)
Cap.( F) 50 120 300 1k 10 50K
10 100 0.88 0.90 1.00 1.15 1.15
160 350 0.85 0.88 1.00 1.15 1.20
400 450 0.88 0.90 1.00 1.10 1.15
Temperature multiplying factor
Temperature( ) 45 60 70 85
Factor 1.46 1.42 1.3 1.00
