Image preview - the first page of the document
![Topmay [snap-in] TMCE18-SR Series](/pics/5c2e12464449a.gif)
>> Download Topmay [snap-in] TMCE18-SR Series documenatation <<
Text preview - extract from the document
TMCE18 SR Series Aluminum Electrolytic Capacitors
Features
Load life of 2,000 hours at 105
Snap-in terminal type,wide temperature range.
Suitable for use in switching power supplies.
Having safety vents.
Specifications
Item Characteristics
Operating temperature range -40 +105 (for 10V to 250V) -25 +105 (for 315V to 400V)
Rated voltage range 10 400V
Capacitance range 39 82,000 F
Capacitance tolerance
20%(M)
(at20 ,120Hz)
After 1 minute application of rated voltage.
Leakage current(I) I 0.02CV or 5mA,whichever is smaller.
(at20 ) Where C: Nominal capacitance in F,V:Rated voltage in V.
W.V.(V) 10 16 25 35 50 60 100 160 200 250 450
Dissipation factor(Tan ) Tan (max.) 0.50 0.40 0.30 0.25 0.20 0.15 0.12 0.15
(at 20 ,120Hz)
For capacitance of more than 1,000 F,add 0.02 for every increase of 1,000 F.
W.V.(v) 10 16 25 35 50 63 80 100 160 250 315 400
Low temperature characteristics
impedance ratio Z-25 /Z+20 4 3 2 3 4
(at 120Hz)
ZT/Z+20 (max) Z-40 /Z+20 6 5 6 -
15 10 8
The following specifications shall be satisfied when the capacitors are restored to
20 after the rated voltage has been applied for 2,000 hours at 105
Load life Capacitance change 20% of the initial value
tan 200% of the initial specified value
I The initial specified value
The following specifications shall be satisfied when the capacitors are restored
to 20 after exposing them at 105 for 1,000 hours without voltage applied
Shelf life Capacitance change 20% of the initial value
tan 150% of the initial specified value
I 200% of the initial specified value
Others Satisfies characteristic W of JIS C5141
Dimensions
1
TMCE18 SR Series Aluminum Electrolytic Capacitors
Case Size DxL(mm) and Maximun Ripple curr ent(A rm s/at 105 ,120Hz)
W.V.(V) 10 16
Cap.( F) D 22 25 30 35 22 25 30 35
6,800 22 25 1.42
8,200 22 30 1.69
10,000 22 25 1.54 22 30 1.86 25 25 1.86
12,000 22 30 1.82 22 35 2.18 25 30 2.20
15,000 22 30 2.04 25 25 2.04 22 40 2.58 25 35 2.65 30 25 2.55
18,000 22 35 2.39 25 30 2.41 22 50 3.12 25 35 2.87 30 30 3.00
22,000 22 40 2.80 25 35 2.84 30 25 2.76 25 45 3.54 30 30 3.31 35 25 3.40
27,000 22 50 3.42 25 40 3.33 30 30 3.28 25 50 4.10 30 35 3.91 35 30 4.03
33,000 25 45 3.87 30 35 3.86 35 25 3.72 30 40 4.57 35 35 4.73
39,000 25 50 4.41 30 35 4.20 35 30 4.33 30 45 5.22 35 35 5.15
47,000 30 40 4.88 35 35 5.05 35 40 5.96
56,000 30 50 5.86 35 35 5.52 35 45 6.66
68,000 35 40 6.42
82,000 35 45 7.74
W.V.(V)
25 35
Cap.( F) D 22 25 30 35 22 25 30 35
3,300 22 25 1.25
3,900 22 30 1.47
4,700 22 25 1.37 22 35 1.72 25 25 1.61
5,600 22 30 1.61 22 35 1.88 25 30 1.90
6,800 22 30 1.77 25 25 1.77 22 40 2.20 25 35 2.23 30 25 2.17
8,200 22 35 2.08 25 30 2.10 22 50 2.67 25 40 2.59 30 30 2.56
10,000 22 40 2.43 25 35 2.47 30 25 2.40 30 45 3.01 30 35 3.10 35 25 2.90
12,000 22 45 2.81 25 40 2.86 30 30 2.83 25 50 3.46 30 35 3.30 35 30 3.40
15,000 25 45 3.37 30 35 3.36 35 25 3.24 30 45 4.10 35 35 4.04
18,000 25 50 3.87 30 35 3.68 35 30 3.80 30 50 4.69 35 40 4.67
22,000 30 45 4.53 35 35 4.46 35 45 5.42
27,000 30 50 5.25 35 40 5.22 35 50 6.28
33,000 35 45 6.06
39,000 35 50 6.89
W.V.(V)
50 63
Cap.( F) D 22 25 30 35 22 25 30 35
1,200 22 25 0.98
1,500 22 30 1.18
1,800 22 25 1.04 22 30 1.29 25 25 1.29
2,200 22 30 1.23 22 35 1.52 25 30 1.54
2,700 22 35 1.46 25 25 1.37 22 40 1.79 25 35 1.81 30 25 1.76
3,300 22 35 1.62 25 30 1.63 22 50 2.18 25 40 2.12 30 30 2.10
3,900 22 40 1.86 25 35 1.89 30 25 1.84 25 45 2.43 30 35 2.43 35 25 2.33
4,700 22 50 2.26 30 30 2.20 25 50 2.80 30 35 2.66 35 30 2.75
5,600 22 50 2.26 22 45 2.40 30 30 2.30 25 25 2.42 30 40 3.07 35 35 3.18
6,800 25 50 2.91 30 35 2.77 35 30 2.86 30 50 3.73 35 35 3.51
8,200 30 40 3.22 35 35 3.34 35 40 4.07
10,000 30 50 3.92 35 35 3.69 35 50 4.93
12,000 35 40 4.26
15,000 35 50 5.23
2
TMCE18 SR Series Aluminum Electrolytic Capacitors
W.V.(V)
80 100
Cap.( F) D 22 25 30 35 22 25 30 35
560 22 25 0.67
680 22 30 0.79
820 22 25 0.81 22 30 0.87 25 25 0.87
1,000 22 30 0.96 22 35 1.03 25 30 1.04
1,200 22 30 1.05 25 25 1.05 22 40 1.19 25 30 1.13 30 25 1.18
1,500 22 35 1.26 25 30 1.18 22 45 1.40 25 35 1.35 30 30 1.41
1,800 22 40 1.46 25 30 1.48 30 25 1.44 25 40 1.57 30 30 1.55 35 25 1.59
2,200 22 45 1.70 25 35 1.64 30 30 1.71 25 50 1.91 30 35 1.82 35 30 1.88
2,700 25 40 2.02 30 30 1.90 35 25 1.94 30 40 2.13 35 35 2.21
3,300 25 45 2.34 30 35 2.30 35 30 2.86 30 45 2.48 35 35 2.44
3,900 30 40 2.56 35 35 2.66 35 40 2.81
4,700 30 45 2.96 35 35 2.92 35 45 3.23
5,600 35 40 3.36
6,800 35 45 3.89
W.V.(V) 160 180
Cap.( F) D 22 25 30 35 22 25 30 35
150 22 25 0.39
180 22 25 0.42 22 30 0.46
220 22 30 0.50 25 25 0.50 22 30 0.50 25 25 0.50
270 22 35 0.60 25 30 0.56 22 35 0.60 25 30 0.60
330 22 40 0.70 25 30 0.62 22 40 0.70 25 35 0.71 30 25 0.69
390 22 45 0.80 25 35 0.77 30 25 0.75 22 50 0.84 25 40 0.82 30 30 0.81
470 22 50 0.92 25 40 0.90 30 30 0.88 25 45 0.91 30 35 0.94 35 25 0.91
560 25 45 1.03 30 30 1.03 35 25 0.99 25 50 1.08 30 35 1.03 35 30 1.06
680 25 50 1.19 30 40 1.20 35 30 1.17 30 40 1.20 35 35 1.24
820 30 45 1.38 35 35 1.36 30 45 1.38 35 35 1.36
1,000 30 50 1.60 35 40 1.59 35 40 1.59
1,200 35 45 1.83 35 50 1.91
1,500 35 50 2.14
W.V.(V)
200 250
Cap.( F) D 22 25 30 35 22 25 30 35
100 22 25 0.28
120 22 25 0.35 22 30 0.33
150 22 30 0.42 22 30 0.37 25 25 0.37
180 22 30 0.46 25 25 0.46 22 35 0.44 25 30 0.44
220 22 35 0.54 25 30 0.54 22 40 0.51 25 35 0.52 30 25 0.50
270 22 40 0.63 25 30 0.60 30 25 0.63 22 50 0.62 25 40 0.61 30 30 0.60
330 22 45 0.74 25 35 0.71 30 30 0.74 25 45 0.71 30 30 0.71 35 25 0.68
390 22 50 0.84 25 40 0.82 30 30 0.81 35 25 0.83 25 50 0.81 30 35 0.77 35 30 0.79
470 25 45 0.94 30 35 0.94 35 30 0.97 30 40 0.89 35 35 0.92
560 30 35 1.09 35 30 1.06 30 45 1.02 35 35 1.01
680 30 45 1.26 35 35 1.24 35 40 1.17
820 30 50 1.45 35 35 1.44 35 45 1.41
1,000 35 45 1.67
1,200 35 50 1.91
3
TMCE18 SR Series Aluminum Electrolytic Capacitors
W.V.(V)
315 350
Cap.( F) D 22 25 30 35 22 25 30 35
47 22 25 0.19
56 22 30 0.23
68 22 25 0.23 22 30 0.25 25 25 0.25
82 22 30 0.28 22 35 0.29 25 30 0.30
100 22 30 0.30 25 25 0.30 22 40 0.34 25 30 0.33 30 25 0.34
120 22 35 0.36 25 30 0.36 22 45 0.40 25 35 0.38 30 30 0.40
150 22 40 0.42 25 35 0.43 30 25 0.42 25 40 0.45 30 30 0.45 35 25 0.46
180 22 45 0.49 25 40 0.47 30 30 0.49 25 45 0.52 30 35 0.52 35 30 0.54
220 25 45 0.55 30 30 0.54 35 25 0.55 30 40 0.61 35 30 0.59
270 25 50 0.67 30 35 0.64 35 30 0.66 30 45 0.71 35 35 0.70
330 30 40 0.75 35 35 0.77 35 40 0.82
390 30 45 0.85 35 35 0.84 35 45 0.93
470 35 40 0.97
560 35 45 1.12
W.V.(V) 400 450
Cap.( F) D 22 25 30 35 22 25 30 35
39 22 25 0.18
47 22 25 0.19 22 30 0.21 25 25 0.21
56 22 30 0.23 22 35 0.24 25 30 0.25
68 22 30 0.25 25 25 0.25 22 40 0.28 25 30 0.27
82 22 35 0.29 25 30 0.30 22 45 0.33 25 35 0.32 30 25 0.31
100 22 40 0.34 25 30 0.33 30 25 0.34 22 50 0.38 25 40 0.37 30 30 0.36
120 22 45 0.40 25 35 0.38 30 30 0.40 25 45 0.43 30 35 0.43 35 25 0.41
150 25 40 0.45 30 30 0.45 35 25 0.46 30 40 0.50 35 30 0.49
180 25 45 0.52 30 35 0.52 35 30 0.54 30 45 0.58 35 35 0.57
220 30 40 0.61 35 30 0.59 30 50 0.67 35 40 0.67
270 30 45 0.71 35 35 0.70 35 45 0.78
330 35 40 0.82 35 50 0.90
390 35 45 0.93
470 35 50 1.07
Ripple Current Multipliers
Frequency multiplying factor
Freq(Hz)
Cap.( F) 50 60 120 1k 10 15K
16 100 0.88 0.90 1.00 1.15 1.15
160 250 0.85 0.88 1.00 1.15 1.20
315 450 0.88 0.90 1.00 1.10 1.15
Temperature multiplying factor
Temperature( ) 45 60 70 85 105
Factor 2.47 2.37 2.17 1.67 1.00
