Image preview - the first page of the document
![Topmay [screw-terminal] TMCE21-LS Series](/pics/5c2e1248c89cc.gif)
>> Download Topmay [screw-terminal] TMCE21-LS Series documenatation <<
Text preview - extract from the document
TMCE21 Screw Terminal Aluminum Electrolytic Capacitor 85
Features
Long life of 2,000 hours at 85 .
Screw terminal type.
Suitable for switching power supply, computer, inverter, inotot-control.
Having safety vents.
Characteristics
Item Characteristics
Operating temperature range -40 +85 -25 +85
Rated voltage range 10 100V 160 450V
Capacitance range 3,300 470,000 F 220 15,000 F
Capacitance tolerance
20%(M)
(at20 ,120Hz)
Leakage current (I) After 5 minutes application of rated voltage,
I 0.01CV( A) or 5mA, whichever is smaller.
(at 20 ) Where c: Nominal capacitance in F, v: Rated voltage in V.
W.V. W.V.
35 42 50 65 76 80 35 42 50 65 76 80
(v) (v)
10 0.75 0.85 1.00 1.30 1.50 1.50 63 0.20 0.30 0.30 0.30 0.40 0.40
Dissipation factor (Tan )
( at 20 ,120Hz) 16 0.60 0.65 0.70 0.80 1.00 1.00 80 0.20 0.25 0.25 0.25 0.30 0.30
25 0.40 0.45 0.50 0.70 0.80 0.80 100 0.15 0.20 0.20 0.25 0.25 0.25
35 0.30 0.30 0.50 0.60 0.70 0.70 160/250 0.15 0.15 0.15 0.20 0.20 0.20
50 0.25 0.30 0.30 0.50 0.60 0.60 350/450 0.20 0.20 0.20 0.25 0.25 0.25
W. V. (v) 10 100 160 450
Low temperature characteristics C-25 /C+20 0.7 0.7
(at120Hz) Capacitance ratio
CT/C+20 (max.) C-40 /C+20 0.6 -
The following specifications shall be satisfied when the capacitors are restored
to 20 after the rated voltage has been applied for 2,000 hours at 85 .
Capacitance change 20% of the initial value
Load life
tan 200% of the initial specified value
I The initial specified value
The following specifications shall be satisfied when the capacitors are restored
to 20 after exposing them at 85 for1,000 hours without voltage applied
Shelf life Capacitance change 20% of the initial value
tan 150% of the initial specified value
I 200% of the initial specified value
Others Satisfies characteristic W of JIS C5141
D 1.5 35 42 50 65 76 80
L 50 60 80 60 80 60 80 100 100 120 100 120 100 120
F 0.5 14 15 22 28 32 35
1
TMCE21 Screw Terminal Aluminum Electrolytic Capacitor 85
Case Size DxL(mm) And Maximum Ripple Current
(A rms/at 85 ,120Hz)
W.V.(v)
10 16 25 35 50 63 80
Cap.( F) D L I D L I D L I D L I D L I D L I D L I
3,300 35 50 2.5
4,700 35 60 3.2
6,800 35 50 3.2 35 50 3.5 35 80 4.3
10,000 35 50 3.5 35 60 4.1 35 60 4.6 42 80 5.2
15,000 35 50 3.7 35 60 4.6 35 80 5.8 35 80 6.4 50 80 7.0
22,000 35 50 3.7 35 60 4.8 35 80 6.4 42 80 7.0 42 80 7.0 50 100 9.4
33,000 35 50 4.0 35 60 4.8 42 60 6.2 42 80 8.6 50 80 9.5 50 80 9.5 65 100 12.5
47,000 35 60 5.2 42 60 6.2 42 80 8.4 42 100 11. 4 50 100 12.5 50 100 12.5 65 120 17.5
68,000 35 80 7.1 42 80 8.4 50 80 10.6 50 80 10.6 50 120 16.3 65 100 17.4
100,000 42 80 8.9 50 80 10.8 50 100 14.1 50 120 15.3 65 120 17.7 65 120 22.9
150,000 50 80 11.1 50 100 14.6 65 100 17.0 65 120 19.8
220,000 50 100 14.8 65 100 19.2 65 120 22.2
330,000 65 100 18.5 80 100 23.7
470,000 76 100 22.4
W.V.(v)
100 160 200 250 350 400 450
Cap.( F) D L I D L I D L I D L I D L I D L I D L I
220 35 50 0.6 35 50 0.6 35 50 0.6
330 35 50 0.9 35 50 0.8 35 60 0.8 35 60 0.8
470 35 50 1.1 35 50 1.1 35 60 1.0 35 80 1.1 35 80 1.1
680 35 50 1.3 35 50 1.3 35 60 1.4 35 80 1.4 42 80 1.5 42 80 1.5
1,000 35 50 1.6 35 60 1.7 35 80 1.9 42 80 1.8 50 80 2.0 50 80 2.0
1,500 35 60 2.1 35 80 2.3 42 80 2.6 50 80 2.5 50 100 2.7 50 100 2.7
2,200 42 60 2.8 42 80 3.1 50 80 3.5 50 100 3.3 65 100 3.4 65 100 3.4
3,300 35 60 3.1 50 60 3.8 50 80 4.2 50 100 4.7 65 100 4.2 65 120 4.6 76 120 5.0
4,700 35 80 4.2 50 80 5.1 50 100 5.6 65 100 5.6 76 100 5.5 76 120 5.9 80 150 6.7
6,800 42 80 4.8 50 100 6.7 65 100 6.8 65 120 7.3 80 120 7.4 80 150 8.1
10,000 50 80 6.4 65 100 8.2 65 120 8.9 76 120 9.7 80 150 9.8
15,000 50 100 8.7 76 100 11.0 76 120 11.9
22,000 50 120 11. 4
33,000 65 120 15.9
2
TMCE21 Screw Terminal Aluminum Electrolytic Capacitor 85
Ripple Current Multipliers
Frequency multiplying factor
Freq.(Hz)
W. V. (v) D
50 60 120 360 1K 10K
35 42 0.95 0.96 1.00 1.03 1.04 1.04
10 50 50 65 0.97 0.98 1.00 1.02 1.03 1.03
76 80 0.98 0.99 1.00 1.02 1.03 1.03
35 42 0.90 0.94 1.00 1.09 1.03 1.15
50 65 0.93 0.97 1.00 1.06 1.10 1.13
63 100
76 80 0.95 0.98 1.00 1.03 1.08 1.08
35 42 0.71 0.79 1.00 1.10 1.15 1.21
160 250 50 65 0.83 0.88 1.00 1.08 1.13 1.20
76 80 0.85 0.90 1.00 1.06 1.11 1.20
35 42 0.65 0.74 1.00 1.10 1.16 1.22
50 65 0.81 0.87 1.00 1.08 1.13 1.21
350 450
76 80 0.81 0.87 1.00 1.08 1.13 1.21
Temperature multiplying factor
Temperature ) 45 60 70 85
Factor 1.46 1.42 1.3 1.00
Mounting clamp
D A B W H D E K J
35 62 44 50 3.2 50 32.5 37.0 14
42 64 50 54 3.5 65(63.5) 38.0 43.5 14
50 80 64 68 4.5 76 44.5 50.5 14
65(63.5) 93 76 81 4.5 80 46.5 53.0 16
3
