Image preview - the first page of the document
![Topmay [radial thru-hole] TMCE03-GM Series](/pics/5c2e125cbd247.gif)
>> Download Topmay [radial thru-hole] TMCE03-GM Series documenatation <<
Text preview - extract from the document
TMCE03 2000Hours Aluminum Electrolytic Capacitor 85
Features
Load life of 2,000 hours at 85 .
standard type.
Genetal purpose.
Case Size larger than 5mm diamter has safety vents.
Specifications
Item Characteristics
Operating temperature range -40 +85 (for 6.3V to 250V) -25 +85 (for 350V to 450V)
Rated voltage range 6.3 450V
Capacitance range 0.1-15,000 F
Capacitance tolerance
20%(M)
(at20 ,120Hz)
After 2 minute application of rated voltage. After 2 minute application of rated voltage.
Leakage current(I) I 0.01CV or 3 A,whichever is greater
(for 6.3v to 100v). I 0.02CV 20 A(for 160v to 450v).
(at20 )
Where C: Nominal capacitance in F,V:Rated voltage in V.
W.V.(V) 6.3 10 16 25 35 50 63 100 160-250 350-450
Dissipation factor(Tan ) Tan (max.) 0.24 0.20 0.16 0.14 0.12 0.10 0.09 0.08 0.15 0.20
(at 20 ,120Hz)
For capcitance of more than 1,000 F,add 0.02 for every increase of 1,000 F.
W.V.(v) 6.3 10 16 100 160 250 350 450
Low temperature characteristics 4
impedance ratio Z-25 /Z+20 4 3 2 6
(at 120Hz)
ZT/Z+20 (max) Z-40 /Z+20 8 6 4 8 -
The following specifications shall be satisfied when the capacitors are restored
to 20 after the rated voltage has been applied for 2,000 hours at 85 .
Load life Capacitance change 20% of the initial value
tan 200% of the initial specified value
I The initial specified value
The following specifications shall be satisfied when the capacitors are restored
to 20 after exposing them at 85 for 500 hours without voltage applied
Shelf life Capacitance change 20% of the initial value
tan 150% of the initial specified value
I 200% of the initial specified value
Others Satisfies characteristic W of JIS C5141
Dimensions Ripple Cur rent Multipliers
Frequency multiplying factor
Freq(Hz)
W.V.(v) Cap.( F) 50 120 300 1k 10k
0.1 47 0.75 1.00 1.35 1.57 2.00
6.3 100 100 470 0.80 1.00 1.23 1.34 1.50
1,000 15,000 0.85 1.00 1.10 1.13 1.15
160 450 0.47 470 0.80 1.00 1.25 1.40 1.60
D 0.5 5 6.3 8 10 13 16 18 22 Temperature multiplying factor
1.0 2.0
L
11 11 12 12 16 20 20 25 25 30 35 35 40 35 40 65
Temperature( ) 45 85
F 0.5 2.0 2.5 3.5 5.0 7.5 10.0
d 0.05 0.5 0.6 0.8 Factor 1.59 1.23 1.00
1
TMCE03 2000Hours Aluminum Electrolytic Capacitor 85
Case Size DxL(mm) and Maximun Ripple curr ent(mA/at85 ,120Hz)
W.V.(v)
6.3 10 16 25 35 50 63 100 160 200 250 350 400 450
Cap.( F)
5 11 5 11
0.1 1.3 2.6
5 11 5 11
0.22
2.9 5.8
5 11 5 11
0.33
4.3 8.7
5 11 5 11 5 11 5 11 5 11 6.3 11 6.3 11 6.3 11
0.47
6.3 11 8.2 8.2 8.2 8.1 8.1 8.1
5 11 5 11 5 11 5 11 6.3 11 6.3 11 8 12 8 12
1
13 16 12 12 14 12 14 14
5 11 5 11 6.3 11 6.3 11 6.3 11 8 12 10 12 10 12
2.2
22 24 20 20 20 21 24 24
5 11 5 11 6.3 11 6.3 11 8 12 10 12 10 16 10 16
3.3
27 30 25 25 30 29 33 33
5 11 5 11 5 11 5 11 5 11 8 12 8 12 10 12 10 16 10 16 10 20
4.7
27 29 32 34 36 35 35 40 39 39 43
5 11 5 11 5 11 5 11 5 11 6.3 11 10 12 10 12 10 16 10 12 10 12 13 20
10
37 39 42 47 49 59 59 59 66 63 63 73
5 11 5 11 5 11 5 11 5 11 6.3 11 8 12 10 16 10 20 10 20 13 20 13 25 16 25
22
49 55 58 63 69 83 105 98 108 108 109 120 135
5 11 5 11 5 11 5 11 5 11 6.3 11 6.3 11 10 12 10 20 13 20 13 20 16 25 16 25 16 30
33
55 60 67 71 77 96 101 146 133 154 154 165 165 178
5 11 5 11 5 11 5 11 6.3 11 6.3 11 8 12 10 16 13 20 13 20 13 25 16 30 16 35 16 35
47
65 71 80 85 105 115 144 196 183 183 202 213 228 228
5 11 5 11 6.3 11 6.3 11 8 12 8 12 10 12 10 20 16 25 16 25 16 30 18 40 22 35 22 35
100
95 104 132 142 182 199 239 316 331 331 359 355 398 398
6.3 11 6.3 11 8 12 8 12 10 12 10 16 10 20 13 25 18 35 18 40 22 35
220
160 176 234 250 307 380 442 599 608 646 681
6.3 11 8 12 8 12 10 12 10 16 10 20 13 20 16 25 22 35 22 35
330
196 256 286 348 425 513 627 824 834 834
8 12 8 12 10 12 10 16 10 16 13 20 13 25 16 30 22 40
470
279 306 389 470 507 710 825 1,065 1,055
10 12 10 16 10 16 13 20 13 20 13 25 16 30 22 35
1,000
463 573 641 875 945 1,141 1,465 1,988
10 12 13 20 13 20 13 25 16 25 18 35 22 35
2,200
822 1,035 1,145 1,338 1,609 2,151 2,515
13 20 13 20 13 25 16 25 16 35 18 40 22 40
3,300
1,124 1,214 1,197 1,738 2,137 2,894 3,003
13 20 13 25 13 25 16 35 18 40 22 40
4,700
1,275 1,506 1,835 2,226 2,652 3,134
16 25 16 25 16 35 18 40 22 40
6,800
1,789 1,901 2,362 2,781 3,241
16 30 16 35 18 40 22 35
10,000
2,144 2,414 2,892 3,144
18 35 18 40 22 35
15,000
2,698 2,981 3,284
Note:10 12 can also be 8 15 as per customer's request.
