Image preview - the first page of the document
>> Download Teapo Series Table documenatation <<
Text preview - extract from the document
ALUMINUM ELECTROLYTIC CAPACITORS
M in iatu r e M in ia tu r e
Recommended C o n d u c tiv e Larg e C an
Applications Ch ip Ty p e A lu m in u m A lu m in u m
P o ly m e r Ty p e
6.3~ 100V 160 ~5 00V
A u to m o tiv e s CT HV AK,ST SP LQ
B atter y C h a rg e CF,CR,CG Whole Series Whole Series Whole Series --
D is p lay CG Whole Series Whole Series Whole Series Whole Series
D ig ital S till C am era VP,CG -- -- -- --
H o m e A p p lian ce CG Whole Series Whole Series Whole Series Whole Series
Lig h tin g CG,CF XV,HV SJ,SY,ST,AK SQ,SG,SP --
MB CR,CG,CX Whole Series Whole Series Whole Series --
NB VP -- -- -- --
N etw o rk s CG,CF XV,HV SJ,SY,ST SG,SP --
P o w er CG,CF,CR,CT Whole Series Whole Series Whole Series Whole Series
TF T f ram e -- SV,DV SH,SC SH --
G am in g VP GV,SV SK,SH SK,SH LH,LG
A u d io ( s te reo ) -- -- Whole Series Whole Series Whole Series
V e d io (D V D ) VP,CG -- S5,S7,SK,SH,SC,SY SK,SH --
To y s VP -- SK SK LH
1 Conductive Polymer Aluminum Solid Electrolytic Capacitors
Series Voltage
Endurance Capacitance
Features Range Page
TEAPO LUXON (+R=With ripple) Range (uF)
(VDC)
CG CG Ultra Low ESR 105 2000hours 2.5 ~25V 33 ~ 2700 25
CP CP 8 mm height & Ultra Low ESR 105 3000hours 2.5 ~25V 10 ~ 1200 28
CY CY Ultra Low ESR with sleeve NEW 105 2000hours 6.3 ~16V 150 ~ 1800 30
CZ CZ Ultra Low ESR with Small size NEW 105 2000hours 2.5 ~16V 10 ~ 2200 32
CR CR Ultra Low ESR & Higher Ripple Current 105 2000hours 2.5 ~6.3V 470 ~ 2700 34
Ultra Low ESR & Higher Ripple Current
CX CX NEW 105 2000hours 2.5 ~28V 33~ 820 36
with bright Aluminum case
CF CF Super Low ESR & Large Capacitance 105 2000hours 6.3 ~32V 68~ 1800 38
CS CS High Voltage & Long Life NEW 105 5000hours 25~50V 56~390 40
CH CH Ultra Low ESR & Long Life NEW 105 5000hours 2.5 ~16V 270 ~ 820 42
CT CT High Temperature NEW 125 1000hours 6.3 ~25V 33 ~ 1000 44
VP VP SMD Strandard NEW 105 2000hours 2.5-16V 22 ~ 1500 46
VB VB SMD Low Profile NEW 105 2000hours 2.5~16V 68~560 49
VS VS SMD Long life and Ultra low ESR NEW 105 5000hours 4~16V 39~330 51
ALUMINUM ELECTROLYTIC CAPACITORS
2 Surface Mount Aluminum Electrolytic Capacitors
Voltage
Low Impedance
Capacitance
Low leakage
Low Profile
Series Range
Long Life
General
Range (uF)
Endurance (VDC)
Features Page
(+R=With ripple )
TYPE
TEAPO LUXON
GV GV Low profile V-Chip 85 2000hours * * 4~100 1~1000 53
FV FV Long life V-Chip 85 3000~5000hours * 4~100 1~1000 55
SV SV Low profile V-Chip 105 1000hours * * 4~100 1~1000 57
DV DV Long life V-Chip 105 2000hours * 6.3~100 1~1000 59
ZV ZV Low impedance V-Chip 105 1000hours+R * 4~50 1~1000 61
Vertical Chip
YV YV Low impedance V-Chip NEW 105 1000~2000hours+R * 6.3~50 1~1500 63
EV EV Ultra Low impedance V-Chip 105 2000hours+R * 6.3~35 4.7~1500 65
JV JV Low profile vertical chip NEW 105 2000hours+R * 6.3~35 10~1800 67
XV XV Ultra Low impedance V-Chip 105 3000~5000 hours+R * * 6.3~50 1~1000 69
HV HV Higher temperature range V-Chip 125 2000hours * 6.3~50 47~1000 71
CV CV Low leakage current V-Chip 85 2000hours * 6.3~50 1~1000 73
NV NV Non-polarized V-Chip 105 2000 hours * 6.3~35 1~47 75
3 Miniature Aluminum Electrolytic Capacitors
Series
Low impedance
Long Life
Minlature
Voltage
General
Endurance Capacitance
TYPE
Features Range Page
TEAPO LUXON (+R=With ripple) Range (uF)
(VDC)
SK GR General purpose 85 2000hours * 6.3~500 1~22000 77
Gerenal Type
SE
(SEK)
SE General purpose 105 1000hours * 6.3~450 1~15000 80
SH SM Miniature General purpose 105 2000hours * 6.3~450 1~22000 83
D5 SF 5 mm height 85 1000hours * 4~50 1~330 86
S5 FX 5 mm height 105 1000hours * 4~50 1~470 88
Low Profile
H5 H5 5 mm height 105 2000hours * * 4~50 1~330 90
D7 SS 7 & 9 mm height 85 1000hours * 4~63 1~470 92
S7 SX 7 & 9 mm height 105 1000hours * 4~63 1~470 94
H7 H7 7 & 9 mm height 105 2000hours * * 4~63 1~470 96
ALUMINUM ELECTROLYTIC CAPACITORS
Low Impedance
High Ripple
Series
Long Life
Miniature
Voltage
General
Endurance Capacitance
Features Range Page
(+R=With ripple) Range (uF)
TYPE
(VDC)
TEAPO LUXON
RN RN Non-polar 85 1000hours * * 4~250 1~6800 98
SN RX Non-polar 105 1000hours * * 6.3~250 1~2200 100
Bi/Non - polar
RB RB Non-polar for crossover 85 1000hours * 25~100 1~100 102
SR BP Bi-polar, Horizontal correction 85 1000hours * 25~50 1~33 104
BX BX Bi-polar, Horizontal correction 105 1000hours * 25~50 1~33 106
SB LX Low leakage current 105 1000hours * 6.3~100 1~4700 108
SC LZ Low ESR and high frequency 105 1000~3000hours+R * 6.3~100 4.7~15000 112
SJ LU Low impedance and high ripple 105 1000~5000hours+R * * 6.3~100 5.6~6800 115
SY LT Low impedance and long life 105 2000~6000hours+R * * 6.3~100 22~15000 118
Low Impedance
TA TA Low impedance and long life NEW 105 4000~10000hours+R * * 6.3~35 33~8200 122
ST ST Low impedance and long life 105 4000~10000hours+R * * 6.3~63 6.8~15000 124
SZ LW Ultra low ESR 105 1000~2000hours+R * 6.3~16 470~3300 126
AK AK High Temperature & Long Life 125 2000-5000hours * * 10~63 47-4700 128
SQ LB High ripple and high voltage 105 2000hours+R * 160~450 2.2~220 130
High Ripple
SG LC High ripple and long life 105 3000~5000hours+R * * 160~450 3.3~330 132
SP SP High ripple and long life 105 8000~10000hours+R * * 160~450 3.3~330 134
SU SU High ripple and long life NEW 105 10000~12000hours+R * * 160~450 3.3~330 136
TH TH General purpose 105 2000hours * 250~450 10~150 138
Slim capacitors
NEW
TG TG High ripple and long life NEW 105 3000~5000hours+R * * 250~450 10~150 140
TP TP High ripple and long life NEW 105 8000~10000hours+R * * 160~450 10~330 142
4 Large Can Type Aluminum Electrolytic Capacitors
Sohenl Rroof
Series
Long Life
Minlature
General
Endurance Voltage Capacitance
Features Page
(+R=With ripple) Range (VDC) Range (uF)
TYPE
TEAPO LUXON
LH TW General purpose 85 2000hours+R * 6.3~500 56~120000 144
LG HW General purpose 105 2000hours+R * 6.3~450 47~82000 149
Snap-in
LF LF Long life 85 3000hours+R * 10~450 56~56000 154
LJ LJ Long life 105 3000hours+R * 10~450 270~68000 159
LQ LQ Long life 105 5000hours+R * 160~450 270~2200 164
