Image preview - the first page of the document
Teapo [non-polar radial] SN Series


>> Download Teapo [non-polar radial] SN Series documenatation <<

Text preview - extract from the document
                                  ALUMINUM ELECTROLYTIC CAPACITORS
                Non-polar
  SN            Series

 Features: 105 1000 hours                                                  SN
Recommended Application: Non-polar miniature type for used in                       High Temperature
                            reversing polarity DC voltage circuits         RN
Corresponding product to RoHS



 Specifications
            Item                                                                       Characteristics
Operating Temperature Range      -40 ~ +105                                                  -25~+105
Rated Voltage Range             6.3 ~ 100VDC                                                 160~250VDC
Rated Capacitance Range         1 ~ 2200  F                                        1~100F
Capacitance Tolerance
