                                 ALUMINUM ELECTROLYTIC CAPACITORS
                   High Ripple and long life
   TG              Series

 Features: High temperature life time 5000 hours at 105
 Recommended Applications : High ripple current for Electronic Ballast ,
                                   Power Supply...etc
 Suitable for slim application
 Corresponding product to RoHS

 Specifications
             Item                                                                    Characteristics
Operating Temperature Range                                                            -25~+105
Rated Voltage Range                                                                   250 ~ 450VDC
Rated Capacitance Range                                                                10 ~ 150F
Capacitance Tolerance
