Image preview - the first page of the document



>> Download Teapo [smd] HV Series documenatation <<

Text preview - extract from the document

                         SURFACE MOUNT ALUMINUM ELECTROLYTIC
HV            Ultra Low Impedance & High temperature
              Series

Features : 1251000~ 2000 hours ,Higher temperature range
Recommended Applications: Automatic Mounting and Reflow Soldering
Corresponding product to RoHS

 Specifications
             Item                                                       Characteristics
Operating Temperature Range         -40 ~ +125
Rated Voltage Range (WV)        10 ~ 50VDC
Capacitance Range               47 ~ 1000F
Capacitance Tolerance
