Image preview - the first page of the document



>> Download UB [bi-polar radial] ACM-CD71XH Series documenatation <<

Text preview - extract from the document

SUPER-MINIATURE ALUMINUM ELECTROLYTIC CAPACITOR--Bi-polarized, 105
                                                                               7mm height



ACM-CD71XH
FEATURES
105 7mm height Bi-polarized series



S P E C I F I C AT I O N S
Operating
Temperature Range
                                                       -40~+105
Rated Voltage Range                                    6.3~50VDC
Capacitance
Tolerance
