Image preview - the first page of the document



>> Download UB [radial thru-hole] ACM-CD171 Series documenatation <<

Text preview - extract from the document

HIGH PERFORMANCE ALUMINUM ELECTROLYTIC CAPACITOR--For photo flash


ACM-CD171
FEATURES
Small capacitance change, Low dissipation
factor, High stability


S P E C I F I C AT I O N S
Operating
Temperature Range
                                                    -20~+55
Rated Voltage
Range
                                                   330WV.DC
Capacitance
Tolerance
                                                 -10% +20%(V)
                    I=1C(at 20, 5 minutes ) Max
Leakage current
                    I:Leakage Current  C: Nominal Capacitance

Tan                                            0.06 Max(20, 120Hz)

                    Charge and discharge at rated voltage at 535 in every 30 seconds for
                     5000 times via Xe flesh tube with discharge, resistance of 0.71.0
Charge and                 Leakage Current          Not more than 150% of specified value
Discharge
                          Capacitance Change        Within
