Image preview - the first page of the document



>> Download Vishay [radial thru-hole] 150 RMI Series documenatation <<

Text preview - extract from the document

150 RMI
Vishay BCcomponents

                                           Aluminum Capacitors
                                     Radial Miniature, Low Impedance
                                                                           FEATURES
                                                                            Polarized aluminum electrolytic capacitors,
                                                                            non-solid electrolyte
                                                                            Radial leads, cylindrical aluminum case with       RoHS
                                                                                                                                COMPLIANT
                                                                            pressure relief, insulated with a blue sleeve
                                                                            Charge and discharge proof
                                                                            Very long useful life:
                                                                            4000 h to 10 000 h at 105 C, high stability, high reliability
                                                                            Very low impedance or ESR respectively, at smaller case
                     Fig.1 Component outline                                sizes than the 136 RVI series
                                                                            Excellent ripple current capability
                                               136 RVI                      AEC-Q200 qualified
                                                                            Compliant to RoHS Directive 2002/95/EC
                                              miniaturize
                                                                           APPLICATIONS
                                                                            Power supplies (SMPS, DC/DC converters) for general
              048 RML                                                       industrial,   EDP,      audio-video, automotive and
                              lower Z
                                               150 RMI                      telecommunications
                            longer life
              148 RUS
                                                                            Smoothing, filtering, buffering

 QUICK REFERENCE DATA                                                      MARKING
 DESCRIPTION                                         VALUE                 The capacitors are marked (where possible) with the
 Nominal case sizes (
