Image preview - the first page of the document
>> Download Xunda Series Table documenatation <<
Text preview - extract from the document
Series Chart
MINIATURE ALUMINUM ELECTROLYTIC CAPACITORS
Sleeve
Temperature Voltage Capacitance Load life
Series Features marking
(V.DC) (F) (HOURS)
Miniature type
SL 5mmL,Standard White color letter on -40+85 6.350 0.1330 1000
5 purple sleeve
SS(CD50) 5mmL,Standard White color letter on -40+105 6.350 0.1330 1000
5 black sleeve
SG 7mmL,Standard White color letter on -40+85 6.350 0.1470 1000
7 purple sleeve
SM(CD11X) 7mmL,Standard White color letter on -40+105 6.350 0.1470 1000
7 black sleeve
SK 7mmL,longlife White color letter on -40+105 6.350 0.1470 2000
7 black sleeve
RA 105Low Cost White color letter on -40+105 6.3450 0.122000 1000
105 black sleeve
RB(CD110) 85 Standard White color letter on -40+85 6.3450 0.122000 2000
85 purple sleeve
RK(CD11) 105Standard White color letter on -40+105 6.3450 0.122000 2000
105 black sleeve
RP 105 Pen Type White color letter on -40+105 400450 27220 2000
105 black sleeve
T7 7mmL,105 White color letter on -40+105 6.350 0.1220 1000
Low Impedance green sleeve
7
TM(CD288) High Frequence White color letter on -40+105 6.3450 16800 2000
Low ESR green or black sleeve 4000
(
TP High Frequence White color letter on -40+105 6.350 16800 3000
Low ESR green or black sleeve 7000
LongLifeAssurance (
TS Special Low ESR White color letter on -40+105 6.350 226800 3000
LongLifeAssurance green sleeve 7000
TY Special Low ESR White color letter on -40+105 6.350 226800 4000
LongLifeAssurance green sleeve 10000
TR High Frequence Gold color letter on -40+105 6.316 4704700 2000
Utra Low ESR green sleeve
TT High Frequence Gold color letter on -40+105 6.316 4704700 2000
Utra Low ESR green sleeve
RM Long Life White color letter on -40+105 6.3100 0.122000 3000
Assurance black sleeve 8000
RH +125 White color letter on -40+125 1050 14700 1000
High Temperrature black sleeve
+125
RL(CD11T) Designed for electronic White color letter on -40+105 160450 1220 3000
ballast black sleeve
RR Long Life Assurance White color letter on -40+105 160450 1220 5000
High Ripple Current black sleeve
RS Ultra Long Life Assurance White color letter on -40+105 160450 1220 8000
High Ripple Current black sleeve 10000
RT Ultra Long Life Assurance White color letter on -40+105 160450 1220 8000
High Ripple Current black sleeve 12000
RU +130 White color letter on -40+130 160450 2.2220 2000
High Temperrature black sleeve 3000
Designed for electronic
ballast
+125
RV +130 White color letter on -40+130 160450 2.2220 4000
High Temperrature black sleeve 5000
Designed for electronic
ballast
+125
RW 750WV White color letter on -40+105 400750 1150 2000
High Surge Voltage black sleeve
750WV
RQ +105 Pen Type White color letter on -40+105 400450 1150 10000
Long Life Assurance black sleeve
N7(CD71X) 7mmL,Nonpolar White color letter on -40+105 6.350 0.1220 1000
7 black sleeve
NK(CD71H) +85,Nonpolar White color letter on -40+85 6.3250 16800 1000
+85 purple sleeve
NP(CD71)) +105,Nonpolar White color letter on -40+105 6.3250 16800 1000
+105 black sleeve
NR StandardFor Audio White color letter on -40+85 50/100 168 1000
black sleeve
BK Bi-polarrized White color letter on -40+105 25/50/100 147 2000
TV purple sleeve
BP(CDS) 7mmL,Nonpolar White color letter on -40+105 6.350 0.1220 2000
7 black sleeve
L7 7mmL,Low leakage White color letter on -40+85 6.350 0.1330 1000
Current nacarat sleeve
7
LK(CD113H) +85,Low leakage White color letter on -40+85 6.3100 16800 1000
Current nacarat sleeve
+85
LL(CD113) +105,Low leakage White color letter on -40+105 6.3100 16800 1000
Current black sleeve
+105
PF(CD171) Photo Flash Use White color letter on -40+55 330 80330 5000times
black sleeve
PS(CD17) Recharging And White color letter on -40+55 330/360 3001500 5000times
Discharging in Flash black sleeve
LP(CD293) Lug/Snap-in Terminal White color letter on -4085 6.3450 688200 2000
Type,Standard black sleeve
/
HP(CD293H) Lug/Snap-in Terminal White color letter on -40105 6.3450 688200 2000
Type,Standard black sleeve
/
MP Lug/Snap-in Terminal White color letter on -40105 6.3450 568200 3000
Type,Long Life black sleeve
/
PP Lug/Snap-in Terminal White color letter on -40105 6.3450 568200 5000
Type,Long Life black sleeve
/
QP Lug/Snap-in Terminal White color letter on -40105 6.3450 568200 7000
Type,,Long Life black sleeve
/
WB Screw Terminal White color letter on -4085 10630 10068000 2000
Type,Standard +85 black sleeve
+85
WK(CD13) Screw Terminal White color letter on -40105 10500 18068000 2000
Type,Standard +105 black sleeve
+105
