Image preview - the first page of the document
![YEC [non-polar radial] NPM7 Series](/pics/5c2ba5afe8595.gif)
>> Download YEC [non-polar radial] NPM7 Series documenatation <<
Text preview - extract from the document
JIAN LONG ELECTRONIC(BAO AN)CO.,LTD
ALUMINUM ELECTROLYTIC CAPACITOR
NPM7 series
Feature
1. 85 7mm Height. Nonpolar.
85 7mm .
2. Load life:85 1000 hours
:85 1000
3. NPM7NPH7 ( high reliability 105 1000 hours)
NPM7NPH7 ( 105 1000 )
Specification
Item Performance Characteristic
Operating Temperature Range
-40~+85
Rated Working Voltage Range 6.3~50V.DC
Capacitance Tolerance 20% (at 20, 120Hz )
The rated voltage shall be applied across Capacitor & its protective resistor of 1000
whichever is greater (after 2 minute) at 20
( 1 0 0 0) 2 2 0
Leakage Current(Max)at 20
: 1 0A .
I=0.05CV or 10A (minimum)
I =Leakage Current(A) C= Capacitance(F ) V= Rated Voltage(V)
I= C= V=
Rated Voltage
Dissipation Factor(Max) (V) 6.3 10 16 25 35 50
at 120Hz 20
Tan 0.26 0.22 0.18 0.17 0.15 0.14
After 1000 hours application of rated voltage at 85 with the polarity inverted every 250
hours, capacitors meet the characteristic of following requirements.
8 5 2 5 0 1000
Variation of capacitance Within 25% of the initial value
Load Life 25%
Tan 200% or less of initial specified value
200%
Leakage current Initial specified value or less
Appearance Without distinct damage
The following specification shall be satisfied when the capacitors are stored to 20 after
Shelf Life exposing them for 1000 hours at 85 without voltage applied, The capacitors meet the
specified value for load life characteristics listed above.
85 1000 20
" "
Impedance Ratio At 120Hz
Rated Voltage
Stability At Low Temperature (V) 6.3 10 16 25 35 50
Z(-25)/Z(20) 4 3 3 2 2 2
Z(-40)/Z(20) 10 8 6 4 4 4
43
JIAN LONG ELECTRONIC(BAO AN)CO.,LTD
ALUMINUM ELECTROLYTIC CAPACITOR
NPM7 series
Case sizes and Dimensions Multiplier for ripple current
Frequency Coefficient
Outline Darwing Frequency
Sleeve d 0.1 60(50) 120 500 1K 10K
Steel wire(tinned) (Hz)
+
0.1~47F 0.80 1.00 1.20 1.30 1.50
D+0.5max
Coefficient
- F 0.5
100~220F 0.80 1.00 1.10 1.15 1.20
L+1 max 15min 4min
Temperature Coefficient
Lead spacing and wire diameter(unit:mm)
Ambient Temperature
() 85 70 50
D 4 5 6.3 8
F 1.5 2.0 2.5 3.5 Coefficient
1.0 1.6 2.0
d 0.45 0.5
Standard Size( DXLmm) & Rated Ripple Current(mA r.m.s.) at 85 120HZ
X R .C .= mA r.m.s. )
WV(V.DC)
6.3 10 16 25 35 50
C a p (F )
SIZE R.C. SIZE R.C. SIZE R.C. SIZE R.C. SIZE R.C. SIZE R.C.
0.1 4X7 1
0.22 4X7 2
0.33 4X7 3
0.47 4X7 5
0.68 4X7 8
1 4X7 10
2.2 4X7 10 5X7 14
3.3 4X7 15 5X7 16 5X7 19
4.7 4X7 15 5X7 20 5X7 20 6.3X7 26
6.8 5X7 20 6.3X7 25 6.3X7 30 8X7 33
10 4X7 20 5X7 25 6.3X7 35 6.3X7 35 8X7 44
15 5X7 25 6.3X7 30 6.3X7 40 8X7 45 8X7 50
22 5X7 30 5X7 35 6.3X7 45 6.3X7 50 8X7 60 8X7 65
33 5X7 40 6.3X7 45 6.3X7 60 8X7 70 8X7 75
47 6.3X7 55 6.3X7 65 6.3X7 65 8X7 85
100 8X7 90 8X7 100 8X7 120
220 8X7 130
44
