Image preview - the first page of the document
![YEC [radial thru-hole] SL5 Series](/pics/5c2ba6f1b12c8.gif)
>> Download YEC [radial thru-hole] SL5 Series documenatation <<
Text preview - extract from the document
JIAN LONG ELECTRONIC(BAO AN)CO.,LTD
ALUMINUM ELECTROLYTIC CAPACITOR
SL5 series
Feature
1. 85 5mm Height. For low leakage current
85 5mm .
2. Load life:85 1000 hours
:85 1000
3. Sl5HL5 ( high reliability 105 1 000 hours)
SL5HL 5 ( 105 1 000 )
Specification
Item Performance Characteristic
Operating Temperature Range
-40~+85
Rated Working Voltage Range 4~50V.DC
Capacitance Tolerance
20% (at 20, 120Hz )
The rated voltage shall be applied across Capacitor & its protective resistor of 1000 whichever
is greater (after 2 minute) at 20
( 1000) 2 20
Leakage Current(Max)at 20
: 0.4A.
I=0.002CV or 0.4A (minimum)
I =Leakage Current(A) C= Capacitance(F ) V= Rated Voltage(V)
I= C= V=
Dissipation Factor(Max) Rated Voltage
4 6.3 10 16 25 35 50
(V)
at 120Hz 20
Tan 0.35 0.24 0.20 0.16 0.14 0.12 0.10
After 1000 hours application of rated voltage at 85, capacitors meet the characteristic
of following requirements.
85, 1000
V ariation of capacitance Within 25% of the initial value
Load Life 25 %
Tan 200% or less of initial specified value
200%
Leakage current Initial specified value or less
Appearance Without distinct damage
The following specification shall be satisfied when the capacitors are stored to 20 after
exposing them for 1000 hours at 85 without voltage applied, The capacitors meet the
Shelf Life
specified value for load life characteristics listed above.
85 1000 20
" "
Impedance Ratio At 120Hz
Rated Voltage
4 6.3 10 16 25 35
Stability At Low Temperature (V) 50
Z(-25)/Z(20) 7 4 3 2 2 2 2
Z(-40)/Z(20) 15 10 8 6 4 3 3
29
JIAN LONG ELECTRONIC(BAO AN)CO.,LTD
ALUMINUM ELECTROLYTIC CAPACITOR
SL5 series
Case sizes and Dimensions Multiplier for ripple current
Frequency Coefficient
Outline Darwing
Frequency
Sleeve d 0.1 60(50) 120 500 1K 10K
Steel wire(tinned) (Hz)
+
0.1~47F 0.80 1.00 1.20 1.30 1.50
D+0.5max
Coefficient
-
F 0.5
68~100F 0.80 1.00 1.10 1.15 1.20
L+1 max 15min 4min
Temperature Coefficient
Lead spacing and wire diameter(unit:mm)
Ambient Temperature
D 4 5 () 85 70 50
6.3
F 1.5 2.0 2.5 Coefficient
1.0 1.6 2.0
d 0.45
Standard Size( DXLmm) & Rated Ripple Current(mA r.m.s.) at 85 120HZ
X R.C.= mA r.m.s. )
WV(V.DC)
4 6.3 10 16 25 35 50
C a p ( F )
SIZE R.C. SIZE R.C. SIZE R.C. SIZE R.C. SIZE R.C. SIZE R.C. SIZE R.C.
0.1 4X5 1
0.22 4X5 2
0.33 4X5 2.5
0.47 4X5 4
0.68 4X5 6
1 4X5 8
2.2 4X5 9
3.3 5X5 13
4.7 4X5 13 4X5 14 5X5 20
6.8 5X5 20 5X5 20 6.3X5 25
10 4X5 18 5X5 25 5X5 27 6.3X5 30
15 5X5 25 6.3X5 30 6.3X5 35
22 4X5 22 5X5 30 5X5 35 6.3X5 42 6.3X5 44
33 5X5 25 5X5 34 5X5 40 6.3X5 48 6.3X5 50
47 5X5 32 5X5 37 6.3X5 50 6.3X5 58
68 6.3X5 45 6.3X5 55
100 6.3X5 55 6.3X5 62
