Image preview - the first page of the document
![YEC [radial thru-hole] SL Series](/pics/5c2ba72128364.gif)
>> Download YEC [radial thru-hole] SL Series documenatation <<
Text preview - extract from the document
JIAN LONG ELECTRONIC(BAO AN)CO.,LTD
ALUMINUM ELECTROLYTIC CAPACITOR
SL series
Feature
1. 85 Standard sizeFor low leakage current
85
2. Load life:85 2000 hours
:85 2000
3. SLHL ( high reliability 105 1000 hours)
SLHL ( 105 1000 )
Specification
Item Performance Characteristic
Operating Temperature Range
-40~+85
Rated Working Voltage Range
6.3~100V.DC
Capacitance Tolerance 20% (at 20, 120Hz )
The rated voltage shall be applied across Capacitor & its protective resistor of 1000
whichever is greater (after 2 minute) at 20
( 1000) 2 20
Leakage Current(Max)at 20 : 0.4A.
I=0.002CV or 0.4A (minimum)
I =Leakage Current(A) C= Capacitance(F ) V= Rated Voltage(V)
I= C= V=
T an value to be increased by 0.02 per 1000F for capacitance values greater than 1000F.
Dissipation Factor(Max) 1 0 0 0F 1 0 0 0Ft a n 0.02
at 120Hz 20 Rated Voltage
6.3 10 16 25 35 50 63 100
(V)
Tan 0.22 0.19 0.16 0.14 0.12 0.10 0.09 0.08
After 2000 hours application of rated voltage at 85, capacitors
meet the characteristic of following requirements.
85 2000
V ariation of capacitance Within 20% of the initial value
Load Life 20%
Tan 200% or less of initial specified value
200%
Leakage current Initial specified value or less
Appearance Without distinct damage
The following specification shall be satisfied when the capacitors are stored to 20 after
Shelf Life exposing them for 1000 hours at 85 without voltage applied, The capacitors meet the
specified value for load life characteristics listed above.
8 5 1000 2 0
" "
Impedance Ratio At 120Hz
Rated Voltage
Stability At Low Temperature (V) 6.3 10 16 25 35 50 63 100
Z(-25)/Z ( 2 0) 4 3 2 2 2 2 2 2
Z(-40)/Z ( 2 0) 8 6 4 4 3 3 3 3
33
JIAN LONG ELECTRONIC(BAO AN)CO.,LTD
ALUMINUM ELECTROLYTIC CAPACITOR
SL series
Case sizes and Dimensions
Multiplier for ripple current
Frequency Coefficient
Outline Darwing
Vent(except 5) Sleeve d 0.1 Frequency
60(50) 120 500 1K 10K
Steel wire(tinned) (Hz)
+ 0.1~47F 0.80 1.00 1.20 1.30 1.50
D+0.5max
Coefficient
- F 0.5 100~1000F 0.80 1.00 1.10 1.15 1.20
1500~10000F 0.80 1.00 1.05 1.10 1.15
L+a max 15min 4min
Lead spacing and wire diameter(unit:mm) Temperature Coefficient
D 5 6.3 8 10 12.5/13 16 18 Ambient Temperature
85 70 50
()
F 2.0 2.5 3.5 5.0 7.5
d 0.5 0.5 0.6 0.8 Coefficient
1.0 1.6 2.0
1.0(L20) 2.0(L20)
Standard Size( DXLmm) & Rated Ripple Current(mA r.m.s.) at 85 120HZ
X R.C.= mA r.m.s. )
WV(V.DC) 35 50 63
6.3 10 16 25 100
C a p (F )
SIZE R.C. SIZE R.C. SIZE R.C. SIZE R.C. SIZE R.C. SIZE R.C. SIZE R.C. SIZE R.C.
0.1 5X11 1 5X11 2
0.22 5X11 2 5X11 4
0.33 5X11 3 5X11 7
0.47 5X11 5 5X11 10
1 5X11 10 5X11 18
2.2 5X11 20 5X11 25
3.3 5X11 35 5X11 45
4.7 5X11 30 5X11 35 5X11 40 5X11 50
10 5X11 40 5X11 50 5X11 55 5X11 60 6.3X11 75 8X11.5 90
22 5X11 45 5X11 50 5X11 70 5X11 85 5X11 90 6.3X11 100 8X11.5 110 10X12.5 130
33 5X11 55 5X11 70 5X11 90 5X11 100 6.3X11 120 6.3X11 130 8X11.5 160 10X16 180
47 5X11 75 5X11 90 5X11 110 6.3X11 130 6.3X11 140 8X11.5 180 10X12.5 200 10X20 220
100 5X11 100 6.3X11 140 6.3X11 180 8X11.5 210 8X11.5 240 10X12.5 290 10X20 330 12.5X20 370
220 6.3X11 220 8X11.5 280 8X11.5 300 10X12.5 360 10X16 410 10X20 480 12.5X20 540 16X25 580
330 8X11.5 310 8X11.5 360 10X12.5 400 10X16 470 10X20 530 12.5X20 600 12.5X25 700 16X31.5 730
470 8X11.5 380 10X12.5 460 10X16 520 10X20 600 12.5X20 670 16X25 750 16X25 840 18X35.5 910
680 10X16 480 10X20 590 12.5X20 720 12.5X25 800 16X25 830 16X25 900 16X31.5 1050
1000 10X16 650 10X20 750 12.5X20 900 12.5X25 1000 16X25 1100 16X31.5 1140 18X35.5 1320
1500 12.5X20 900 12.5X25 1020 16X25 1150 16X31.5 1260 16X35.5 1380 18X41 1480
2200 12.5X20 1050 12.5X25 1180 16X25 1300 16X35.5 1430 18X35.5 1580
3300 16X25 1260 16X31.5 1400 16X35.5 1550 18X41 1720
4700 16X31.5 1500 16X35.5 1630 18X35.5 1800
6800 18X35.5 1750 18X35.5 1880
10000 18X41 1900
