Image preview - the first page of the document
![YEC [radial thru-hole] YHL Series](/pics/5c2ba7463b422.gif)
>> Download YEC [radial thru-hole] YHL Series documenatation <<
Text preview - extract from the document
JIAN LONG ELECTRONIC(BAO AN)CO.,LTD
ALUMINUM ELECTROLYTIC CAPACITOR
YHL series
Feature
1. 105 Standard ripple current,long life.
105 , .
2. Load life:105 2000 hours
:105 2000
3. YHLLZ ( high ripple current and low impedance)
YHLLZ( )
Specification
Item Performance Characteristic
Operating Temperature Range
-40~+105
Rated Working Voltage Range
6.3~100V.DC
Capacitance Tolerance
20% (at 20, 120Hz )
The rated voltage shall be applied across Capacitor & its protective resistor of 1000
whichever is greater (after 2 minute) at 20
( 1000) 2 20
Leakage Current(Max)at 20
: 3A.
I=0.01CV or 3A (minimum)
I =Leakage Current(A) C= Capacitance(F ) V= Rated Voltage(V)
I= C= V=
F or capacitance of more than 1000F , add 0.02 for every increase of 1000F .
Dissipation Factor(Max) 1 0 0 0F 1 0 0 0Ft a n 0.02
at 120Hz 20 Rated Voltage
(V) 6.3 10 16 25 35 50 63 100
Tan 0.22 0.19 0.16 0.14 0.12 0.10 0.09 0.08
After 2000 hours application of rated voltage at 105 , capacitors meet the characteristic
of following requirements.
1 0 5 2000
Variation of capacitance Within 25% of the initial value
Load Life 25%
Tan 200% or less of initial specified value
200%
Leakage current Initial specified value or less
Appearance Without distinct damage
The following specification shall be satisfied when the capacitors are stored to 20 after
exposing them for 1000 hours at 105 without voltage applied, The capacitors meet the
Shelf Life
specified value for load life characteristics listed above.
1 0 5 1000 2 0
" "
Impedance Ratio At 120Hz
Rated Voltage
6.3 10 16 25 35 50 63
Stability At Low Temperature (V) 100
Z(-25)/Z(20) 4 3 2 2 2 2 2 2
Z(-40)/Z(20) 8 6 4 3 3 3 3 3
57
JIAN LONG ELECTRONIC(BAO AN)CO.,LTD
ALUMINUM ELECTROLYTIC CAPACITOR
YHL series
Case sizes and Dimensions Multiplier for ripple current
Frequency Coefficient
Outline Darwing Frequency
60(50) 120 1K 10K 100K
Vent(except 5) Sleeve d 0.1 (Hz)
Steel wire(tinned)
6.8~33F 0.45 0.55 0.75 0.90 1.00
+
39~330F
D+0.5max
Coefficient 0.60 0.70 0.85 0.95 1.00
-
F 0.5
390~1000F 0.65 0.75 0.90 0.98 1.00
1200~10000F 0.75 0.80 0.95 1.00 1.00
L+a max 15min 4min
Temperature Coefficient
Lead spacing and wire diameter(unit:mm)
D 5 6.3 8 10 12.5/13 16 18 Ambient Temperature 85 65
105
()
F 2.0 2.5 3.5 5.0 7.5
d 0.5 0.5 0.6 0.8 Coefficient
1.0 1.7 2.1
1.0(L20) 2.0(L20)
Standard Size( DXLmm) & Rated Ripple Current(mA r.m.s.) at 105 100KHZ,
Impedance Z(m)at 20 100KHZ
X R.C.= mA r.m.s. ) Z= m
WV(V.DC)
6.3V 10V 16V 25V
C a p (F )
SIZE R.C. Z SIZE R.C. Z SIZE R.C. Z SIZE R.C. Z
47 5X11 210 580
56 5X11 210 580 5X11 230 450
100 5X11 210 580 5X11 230 450 6.3X11 340 220
120 5X11 215 540 6.3X11 340 220 6.3X11 380 200
150 5X11 210 580 5X11 220 510 6.3X11 380 200 8X11.5 470 150
220 5X11 220 510 6.3X11 340 220 8X11.5 430 180 8X11.5 640 130
330 6.3X11 340 220 8X11.5 430 180 8X11.5 640 130 10X12.5 860 80
470 8X11.5 430 180 8X11.5 640 130 10X12.5 860 80 10X16 1210 60
680 8X11.5 640 130 10X12.5 860 80 10X16 1210 60 10X20 1400 46
820 8X11.5 660 120 10X16 1000 70 10X20 1300 52 10X25 1650 42
1000 8X11.5 680 100 10X16 1210 60 10X20 1400 46 12.5X20 1900 35
1200 10X16 1210 60 10X20 1400 46 10X25 1650 42 12.5X20 2000 31
1500 10X20 1400 46 10X25 1650 42 12.5X20 1900 35 12.5X25 2230 27
2200 10X25 1650 42 12.5X20 1900 35 12.5X25 2230 27 12.5X30 2650 24
2700 10X25 1750 39 12.5X25 2000 31 12.5X30 2650 24 16X25 2930 21
3300 12.5X20 1900 35 12.5X25 2230 27 12.5X30 2750 23 16X31.5 3450 17
3900 12.5X25 2230 27 12.5X30 2650 24 16X25 2930 21 16X35.5 3610 15
4700 12.5X30 2650 24 16X25 2930 21 16X31.5 3450 17 18X35.5 4220 14
6800 16X25 2930 21 16X31.5 3450 17 16X35.5 3610 15
8200 16X31.5 3450 17 16X35.5 3610 15 18X35.5 4220 14
10000 16X35.5 3610 15 18X35.5 4220 14 18X41 4280 12
58
JIAN LONG ELECTRONIC(BAO AN)CO.,LTD
ALUMINUM ELECTROLYTIC CAPACITOR
YHL series
Standard Size( DXLmm) & Rated Ripple Current(mA r.m.s.) at 105 100KHZ,
Impedance Z(m)at 20 100KHZ
X R.C.= mA r.m.s. ) Z= m
WV(V.DC) 63V
35V 50V 100V
C a p (F )
SIZE R.C. Z SIZE R.C. Z SIZE R.C. Z SIZE R.C. Z
6.8 5X11 55 2300
15 5X11 55 2300 6.3X11 115 1200
22 5X11 180 700 6.3X11 75 2000 6.3X11 150 1000
27 6.3X11 200 620 6.3X11 95 1600 8X11.5 230 630
33 5X11 210 580 6.3X11 220 540 6.3X11 115 1200 8X11.5 250 560
39 6.3X11 220 470 6.3X11 230 460 6.3X11 150 1000 8X16 300 450
47 6.3X11 240 390 6.3X11 250 380 8X11.5 190 800 10X12.5 280 430
56 6.3X11 340 220 6.3X11 290 300 8X11.5 230 630 8X20 360 330
68 6.3X11 350 210 8X11.5 360 200 8X16 260 540 10X16 350 310
82 6.3X11 360 200 8X11.5 370 180 8X16 300 450 10X20 460 210
100 8X11.5 370 180 8X11.5 550 170 10X12.5 320 380 10X25 530 200
120 8X11.5 450 160 8X16 730 120 10X16 350 310 12.5X20 690 160
150 8X11.5 640 130 10X12.5 760 120 10X20 400 260 12.5X25 730 140
180 8X16 660 120 8X20 910 91 10X20 460 210 12.5X25 780 120
220 10X12.5 860 80 10X16 1050 84 10X25 530 200 12.5X30 900 100
270 8X20 1050 69 10X20 1220 60 12.5X20 690 160 16X25 1250 73
330 10X16 1210 60 10X25 1440 55 12.5X25 780 120 16X25 1400 65
390 10X20 1300 54 10X25 1500 50 12.5X30 840 110 16X31.5 1570 54
470 10X20 1400 46 12.5X20 1660 45 12.5X30 900 100 18X31.5 1630 47
560 10X25 1650 42 12.5X25 1950 34 12.5X35 1050 83 18X35.5 1700 44
680 12.5X20 1900 35 12.5X30 2310 30 16X25 1250 73 18X35.5 1790 40
820 12.5X25 2000 30 12.5X35 2510 25 16X31.5 1570 54 18X41 2330 36
1000 12.5X25 2230 27 16X25 2550 25 16X35.5 1630 47
1200 12.5X30 2650 24 16X31.5 3010 22 18X35.5 1790 40
1500 12.5X35 2880 22 16X35.5 3150 19 18X41 2330 36
1800 16X25 2930 21 18X31.5 3635 21
2200 16X31.5 3450 17 18X35.5 3680 17
2700 16X35.5 3610 15 18X41 3800 14
3300 18X35.5 4220 14
3900 18X41 4280 12
