Image preview - the first page of the document
>> Download ucc-fp-oscon documenatation <<Text preview - extract from the document FP OS-CON Series TM
OS-CONTM
OS -CON TM -105 C
Low ESR
FP
High CV
Solvent Proof
105 C
Maximum
Temperature
Actual
Size
The FP series is an OS-CON TM series with lower ESR than the FA series. The high capacitance values
plus very low ESR and small size make these capacitors ideal for use in low profile DC-DC converters
and also for stereo and video recorder applications. Other applications for these capacitors include
filter circuits of switching power supplies.
The FP series capacitors are solvent proof. Refer to the Mini-Glossary for cleaning guidelines and
recommended cleaning agents that are compatible with United Chemi-Con products.
Summary of Specifications
Radial lead terminals.
Capacitance range: 68 to 1,200
