Image preview - the first page of the document
>> Download ucc_fa_os-con documenatation <<
Text preview - extract from the document
FA OS-CON Series
OS-CON
OS -CON -105 C
Solvent Proof
FA
Low
Impedance
Long Life
105 C
Maximum
Temperature Actual
Size
The FA series is a new OS-CON series with higher capacitance values and larger case sizes available
than the older CFM series. The low impedance characteristic makes these parts ideal for use in low
profile DC-DC converters and also for stereo and video recorder applications. These capacitors can
be used in filter circuits of switching power supplies and also for noise limiters.
The FA series capacitors were developed to withstand HCFC cleaning agents for five minutes
by ultrasonic, vapor or immersion. This solvent proof design allows all circuit board components
to be cleaned together at the same time. Refer to the Mini-Glossary for recommended cleaning
conditions and guidelines.
Summary of Specifications
Radial lead terminals.
Capacitance range: 4.7 to 2,200◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
