Image preview - the first page of the document



>> Download ucc_fra_os-con documenatation <<

Text preview - extract from the document

FRA OS-CON Series                                           TM




  OS-CONTM




                                                                                                                           OS -CON TM -105 C
  Ultra Low ESR




                                                                                                                                               FRA
  High CV
  Solvent Proof
   105 C
  Maximum
  Temperature
                                                Actual
                                                 Size




The FRA series is a new OS-CON TM series from United Chemi-Con featuring ultra low ESR and high
CV values. With a rated lifetime of 2,000 hours at 105 C, these low profile capacitors are available
with a standard working voltage of 4 volts and a capacitance range of 330 to 1,000
