Image preview - the first page of the document
ucc_fs_os-con


>> Download ucc_fs_os-con documenatation <<

Text preview - extract from the document
                           FS OS-CON Series

                             OS-CON
     OS -CON -105 C




                             Solvent Proof
FS




                             Small Size
                             Low
                             Impedance
                              105 C
                             Maximum
                             Temperature                                               Actual
                                                                                       Size




                           The FS series is a new OS-CON series that offers smaller case sizes compared to the other OS-CON
                           series. The FS series capacitors have a very low impedance making these parts ideal for use in low
                           profile DC-DC converters as well as stereo and video recorder applications. These OS-CON
                           capacitors can also be used in filter circuits of switching power supplies.
                           The FS series capacitors were developed to withstand HCFC cleaning agents for five minutes
                           by ultrasonic, vapor or immersion. This solvent proof design allows all circuit board components
                           to be cleaned together at the same time. Refer to the Mini-Glossary for recommended cleaning
                           conditions and guidelines.



                                                             Summary of Specifications

                                  Radial lead terminals.
                                  Capacitance range: 4.7 to 470
