Image preview - the first page of the document
>> Download ucc_fx_os-con documenatation <<
Text preview - extract from the document
FX OS-CON Series TM
OS-CONTM
OS -CON TM -105 C
High CV
FX
Low ESR
Solvent Proof
105 C
Maximum
Temperature Actual
Size
The FX series is a new OS-CON TM series with higher capacitance values per case size than the FP
series. The higher capacitance values allow for a very low ESR, making these capacitors ideal for use
in back-up PC power supply applications. Other applications for the FX capacitors include filter
circuits of switching power supplies.
The FX series capacitors are solvent proof. Refer to the Mini-Glossary for cleaning guidelines and
recommended cleaning agents that are compatible with United Chemi-Con products.
Summary of Specifications
Radial lead terminals.
