Image preview - the first page of the document



>> Download aoz1021ai documenatation <<

Text preview - extract from the document

                                                                                                 AOZ1021
                                                                   EZBuckTM 3A Synchronous Buck Regulator



General Description                                          Features
The AOZ1021 is a synchronous high efficiency, simple            4.5V to 16V operating input voltage range
to use, 3A buck regulator. The AOZ1021 works from a             Synchronous rectification: 100m internal high-side
4.5V to 16V input voltage range, and provides up to 3A          switch and 20m Internal low-side switch
of continuous output current with an output voltage
adjustable down to 0.8V.                                        High efficiency: up to 95%
                                                                Internal soft start
The AOZ1021 comes in an SO-8 packages and is rated              1.5% initial output accuracy
over a -40
