Image preview - the first page of the document
AO4407A - P-Channel Enhancement Mode Field Effect Transistor


>> Download AO4407A - P-Channel Enhancement Mode Field Effect Transistor documenatation <<

Text preview - extract from the document
  AO4407A
  P-Channel Enhancement Mode Field Effect Transistor


 General Description                                             Features

 The AO4407A uses advanced trench technology to                  VDS = -30V
 provide excellent RDS(ON), and ultra-low low gate charge        ID = -12A    (VGS = -10V)
 with a 25V gate rating. This device is suitable for use as      RDS(ON) < 11m (VGS = -20V)
 a load switch or in PWM applications. Standard Product          RDS(ON) < 13m (VGS = -10V)
 AO4407A is Pb-free (meets ROHS & Sony 259                       RDS(ON) < 38m (VGS = -10V)
 specifications).


                                                                                 UIS TESTED!
                                                                 RG, CISS, COSS, CRSS TESTED!




                                                                                              D
                     SOIC-8
                    Top View

            S                    D
            S                    D
            S                    D
                                                                                   G
            G                    D
                                                                                              S



Absolute Maximum Ratings TA=25
