  AO4427
  P-Channel Enhancement Mode Field Effect Transistor

 General Description                                             Features

 The AO4427 uses advanced trench technology to                   VDS (V) = -30V
 provide excellent RDS(ON), and ultra-low low gate               ID = -12.5 A (VGS = -20V)
 charge with a 25V gate rating. This device is suitable          RDS(ON) < 12m (VGS = -20V)
 for use as a load switch or in PWM applications. The            RDS(ON) < 14m (VGS = -10V)
 device is ESD protected. Standard Product AO4427                ESD Rating: 2KV HBM
 is Pb-free (meets ROHS & Sony 259 specifications).
 AO4427L is a Green Product ordering option.
 AO4427 and AO4427L are electrically identical



                                SOIC-8                                    D
                               Top View

                      S                   D
                      S                   D
                                                                 G
                      S                   D
                      G                   D
                                                                          S




Absolute Maximum Ratings TA=25
