  AO4437
  P-Channel Enhancement Mode Field Effect Transistor

 General Description                                                   Features

 The AO4437 uses advanced trench technology to provide                 VDS (V) = -12V
 excellent RDS(ON), low gate charge and operation with gate            ID = -11 A (VGS = -4.5V)
 voltages as low as 1.8V. This device is suitable for use as a         RDS(ON) < 16m (VGS = -4.5V)
 load switch or in PWM applications. It is ESD protected.              RDS(ON) < 20m (VGS = -2.5V)
 Standard Product AO4437 is Pb-free (meets ROHS & Sony
                                                                       RDS(ON) < 25m (VGS = -1.8V)
 259 specifications). AO4437L is a Green Product ordering
                                                                       ESD Rating: 4KV HBM
 option. AO4437 and AO4437L are electrically identical.



                SOIC-8
               Top View                                                       D

           S                D
           S                D
           S                D                                    G
           G                D

                                                                              S




Absolute Maximum Ratings TA=25
