Image preview - the first page of the document



>> Download AO4456 - N - Channel Enhancement Mode Field Effect Transistor documenatation <<

Text preview - extract from the document

  AO4456
  N-Channel Enhancement Mode Field Effect Transistor
  SRFET        TM

 General Description                                        Features
 SRFETTM AO4456/L uses advanced trench technology
 with a monolithically integrated Schottky diode to         VDS (V) = 30V
 provide excellent RDS(ON),and low gate charge. This        ID =20A        (V GS = 10V)
 device is suitable for use as a low side FET in SMPS,      RDS(ON) < 4.6m (VGS = 10V)
 load switching and general purpose applications.           RDS(ON) < 5.6m (VGS = 4.5V)
 AO4456 and AO4456L are electrically identical.
 -RoHS Compliant                                                                       UIS TESTED!
 -AO4456L is Halogen Free                                                          Rg,Ciss,Coss,Crss Tested



                                                                               D

                         S          D
                         S          D
                         S          D                                              SRFETTM
                         G          D                             G                Soft Recovery MOSFET:
                                                                                   Integrated Schottky Diode
                                                                              S


Absolute Maximum Ratings TA=25
