Image preview - the first page of the document



>> Download AO4468 - N-Channel Enhancement Mode Field Effect Transistor documenatation <<

Text preview - extract from the document

  AO4468
  N-Channel Enhancement Mode Field Effect Transistor


 General Description                                     Features
 The AO4468 uses advanced trench technology to
 provide excellent RDS(ON) and low gate charge. This     VDS (V) = 30V
 device is suitable for use as a load switch or in       ID = 11.6A            (V GS = 10V)
 PWM applications. The source leads are separated        RDS(ON) < 14m       (VGS = 10V)
 to allow a Kelvin connection to the source, which       RDS(ON) < 22m       (VGS = 4.5V)
 may be used to bypass the source inductance.
 Standard Product AO4468 is Pb-free (meets ROHS
 & Sony 259 specifications). AO4468L is a Green
 Product ordering option. AO4468 and AO4468L are
 electrically identical.




                                                                             D
                    S             D
                    S             D
                    S             D
                    G             D
                                                                  G
                         SOIC-8
                                                                             S




Absolute Maximum Ratings TA=25
