Image preview - the first page of the document
AO4496 - N-Channel Enhancement Mode Field Effect Transistor


>> Download AO4496 - N-Channel Enhancement Mode Field Effect Transistor documenatation <<

Text preview - extract from the document
  AO4496
  N-Channel Enhancement Mode Field Effect Transistor

 General Description                                                  Features

 The AO4496/L uses advanced trench technology to                      VDS (V) = 30V
 provide excellent RDS(ON) with low gate charge. This                 ID = 10A        (VGS = 10V)
 device is suitable for use as a DC-DC converter                      RDS(ON) < 19.5m (VGS = 10V)
 application. AO4496 and AO4496L are electrically                     RDS(ON) < 26m    (VGS = 4.5V)
 identical.
                                                                      UIS TESTED!
 -RoHS Compliant                                                      Rg, Ciss, Coss, Crss Tested
 -AO4496L is Halogen Free




                                                                                                D

              S                        D
              S                        D
              S                        D                                          G

              G                        D
                                                                                                S
                        SOIC-8



Absolute Maximum Ratings TJ=25
