Image preview - the first page of the document
AO4704L - N-Channel Enhancement Mode Field Effect Transistor with Schottky Diode


>> Download AO4704L - N-Channel Enhancement Mode Field Effect Transistor with Schottky Diode documenatation <<

Text preview - extract from the document
  AO4704
  N-Channel Enhancement Mode Field Effect Transistor with
  Schottky Diode
 General Description                                       Features

 The AO4704 uses advanced trench technology to             VDS (V) = 30V
 provide excellent R  DS(ON), shoot-through immunity and   ID = 13 A (VGS = 10V)
 body diode characteristics.This device is suitable for    RDS(ON) < 11.5m (VGS = 10V)
 use as a synchronous switch in PWM applications.          RDS(ON) < 13m (VGS = 4.5V)
 The co-packaged Schottky Diode boosts efficiency
 further. AO4704 is Pb-free (meets ROHS & Sony
                                                           SCHOTTKY
 259 specifications). AO4704L is a Green Product
                                                           VDS (V) = 30V, IF = 3A, VF<0.5V@1A
 ordering option. AO4704 and AO4704L are
 electrically identical.


                                                                            D      K
                    SOIC-8
             S/A    1    8   D/K
             S/A    2    7   D/K
             S/A    3    6   D/K
               G    4    5   D/K                                      G
                                                                            S      A




Absolute Maximum Ratings T =25
