Image preview - the first page of the document
AO4712 - N-Channel Enhancement Mode Field Effect Transistor


>> Download AO4712 - N-Channel Enhancement Mode Field Effect Transistor documenatation <<

Text preview - extract from the document
  AO4712
  N-Channel Enhancement Mode Field Effect Transistor
 SRFET           TM

 General Description                                          Features
        TM
 SRFET The AO4712 uses advanced trench
 technology with a monolithically integrated Schottky         VDS (V) = 30V
 diode to provide excellent RDS(ON),and low gate              ID =11.2A (VGS = 10V)
 charge. This device is suitable for use as a low side        RDS(ON) < 14.5m (VGS = 10V)
 FET in SMPS, load switching and general purpose              RDS(ON) < 18m (VGS = 4.5V)
 applications. Standard Product AO4712 is Pb-free
 (meets ROHS & Sony 259 specifications).
                                                                                        UIS TESTED!
                                                                              Rg,Ciss,Coss,Crss Tested

                                             D

             S               D
             S
             S
                             D
                             D      G
                                                            SRFET      TM         Soft Recovery MOSFET:
                                                                                  Integrated Schottky Diode
             G               D

                                             S


Absolute Maximum Ratings TA=25
