Image preview - the first page of the document



>> Download AO4850 - Dual N-Channel Enhancement Mode Field Effect Transistor documenatation <<

Text preview - extract from the document

AO4850
Dual N-Channel Enhancement Mode Field Effect Transistor


 General Description                                               Features

 The AO4850 uses advanced trench technology to provide             VDS (V) = 75V
 excellent RDS(ON) and low gate charge. The two MOSFETs            ID = 3.1A     (VGS = 10V)
 may be used in H-bridge, Inverters and other applications.        RDS(ON) < 130m (VGS = 10V)
 AO4850 is Pb-free (meets ROHS & Sony 259                          RDS(ON) < 165m (VGS = 4.5V)
 specifications).




                                                                   D1                       D2


           S2    1     8     D2
           G2    2     7     D2
           S1    3     6     D1
           G1    4     5     D1                             G1                  G2
                                                                   S1                       S2

                SOIC-8



Absolute Maximum Ratings TA=25
